6-12
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R407 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
(CD300)
R409 1-218-977-11 RES-CHIP 100K 5% 1/16W
(CD300)
R413 1-218-937-11 RES-CHIP 47 5% 1/16W
(CD300)
< THERMISTOR >
TH301 1-809-361-21 THERMISTOR (2125)
**************************************************************
A-7074-835-A FS-83 BOARD, COMPLETE
*********************
(Ref.No.;1000 Series)
< CAPACITOR >
C004 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
< CONNECTOR >
CN001 1-691-349-11 CONNECTOR, FFC/FPC (ZIF) 11P
* CN002 1-580-056-21 PIN, CONNECTOR (SMD) 3P
* CN003 1-580-056-21 PIN, CONNECTOR (SMD) 3P
CN004 1-785-283-21 PIN, CONNECTOR (PC BOARD) 14P
< DIODE >
D002 8-719-075-15 DIODE MAZT082H08S0
D003 8-719-075-15 DIODE MAZT082H08S0
D004 8-719-070-95 DIODE TLGU1008(T05,SOY)
D006 8-719-158-49 DIODE MA8120-TX
D007 8-719-027-76 DIODE 1SS357-TPH3
< FUSE >
0F001 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0F002 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0F003 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0F004 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0F005 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0F006 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
< FERRITE BEAD >
FB001 1-414-228-11 FERRITE 0uH
FB002 1-414-228-11 FERRITE 0uH
< LINE FILTER >
LF001 1-411-957-11 FILTER, COMMON MODE
< TRANSISTOR >
Q001 8-729-047-68 TRANSISTOR SSM3K03FE(TPL3)
Q002 8-729-051-49 TRANSISTOR TPC8305(TE12L)
Q003 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q004 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
< RESISTOR >
R004 1-218-953-11 RES-CHIP 1K 5% 1/16W
R005 1-218-944-11 RES-CHIP 180 5% 1/16W
R006 1-216-295-91 SHORT 0
R007 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R008 1-218-985-11 RES-CHIP 470K 5% 1/16W
R009 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R010 1-218-989-11 RES-CHIP 1M 5% 1/16W
R011 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R012 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R013 1-216-150-91 RES-CHIP 10 5% 1/8W
R014 1-218-953-11 RES-CHIP 1K 5% 1/16W
R015 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R016 1-218-973-11 RES-CHIP 47K 5% 1/16W
R017 1-218-985-11 RES-CHIP 470K 5% 1/16W
< SWITCH >
S001 1-786-039-21 SWITCH, TACTILE
(FLASH/MACRO/SELF TIMER/EDIT SEARCH)
S002 1-771-138-82 SWITCH, KEY BOARD (MENU)
**************************************************************
A-7074-836-A JK-208 BOARD, COMPLETE
**********************
(Ref.No.;2000 Series)
BT101 1-756-191-11 BATTERY, LITHIUM (SECONDARY)
< CAPACITOR >
C101 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C104 1-216-864-11 METAL CHIP 0 5% 1/16W
C107 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C108 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
< CONNECTOR >
CN101 1-784-421-11 CONNECTOR, FFC/FPC (ZIF) 27P
CN102 1-794-962-11 CONNECTOR, SQUARE TYPE(USB 5P) (USB)
< DIODE >
D102 8-719-075-15 DIODE MAZT082H08S0
D103 8-719-075-15 DIODE MAZT082H08S0
D104 8-719-075-15 DIODE MAZT082H08S0
D105 8-719-075-15 DIODE MAZT082H08S0
D106 8-719-075-15 DIODE MAZT082H08S0
D108 8-719-075-15 DIODE MAZT082H08S0
D109 8-719-075-15 DIODE MAZT082H08S0
D110 8-719-075-15 DIODE MAZT082H08S0
D111 8-719-073-01 DIODE MA111-(K8).S0
D112 8-719-073-01 DIODE MA111-(K8).S0
D113 8-719-075-15 DIODE MAZT082H08S0
D114 8-719-075-15 DIODE MAZT082H08S0
< FERRITE BEAD >
FB101 1-414-233-22 FERRITE 0uH
FB102 1-500-284-21 FERRITE 0uH
FB103 1-500-284-21 FERRITE 0uH
FB104 1-500-284-21 FERRITE 0uH
FB105 1-500-284-21 FERRITE 0uH
FB106 1-469-324-21 FERRITE 0uH
FB107 1-500-284-21 FERRITE 0uH
FB108 1-500-284-21 FERRITE 0uH
FB109 1-216-295-91 SHORT 0
FB110 1-469-084-21 FERRITE 1MH
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
FS-83CD-334CD-333 JK-208
To Next Page
