Sony MVC-CD200 Service Manual

6-25
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7074-838-A PK-58 (SH) BOARD, COMPLETE
**************************
(Ref.No.;4000 Series)
< CAPACITOR >
C201 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C202 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C203 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C204 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C205 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C206 1-164-856-81 CERAMIC CHIP 18PF 5% 16V
C207 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C208 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C209 1-164-860-11 CERAMIC CHIP 27PF 5% 16V
C211 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C212 1-115-156-11 CERAMIC CHIP 1uF 10V
C213 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C214 1-164-657-11 CERAMIC CHIP 0.015uF 10% 50V
C215 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
0 C216 1-131-959-91 CERAMIC CHIP 12PF 10% 3KV
C301 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C302 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C303 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C304 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C305 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C306 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C307 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C308 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C309 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C310 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C311 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C312 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C313 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C314 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C315 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C316 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C402 1-113-986-11 TANTAL. CHIP 2.2uF 20% 25V
C403 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C404 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C406 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C407 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C408 1-164-872-11 CERAMIC CHIP 82PF 5% 16V
C409 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C411 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C412 1-164-872-11 CERAMIC CHIP 82PF 5% 16V
C413 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C414 1-113-994-11 TANTAL. CHIP 6.8uF 20% 16V
C415 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C416 1-164-346-11 CERAMIC CHIP 1uF 16V
C417 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C418 1-164-346-11 CERAMIC CHIP 1uF 6V
< CONNECTOR >
CN201 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN301 1-770-742-21 CONNECTOR, FFC/FPC 32P
CN302 1-766-348-21 CONNECTOR, FFC/FPC 18P
* CN401 1-774-261-11 CONNECTOR, FFC (ZIF) 24P
< DIODE >
D202 8-719-073-01 DIODE MA111-(K8).S0
D301 8-719-075-15 DIODE MAZT082H08S0
D302 8-719-070-91 DIODE TLSU1008(T05,SOY)
D303 8-719-016-74 DIODE 1SS352-TPH3
D304 8-719-070-93 DIODE TLAU1008(T05,SOY)
D401 8-719-084-47 DIODE 1SV290(TPL3)
D402 8-719-976-96 DIODE MA8047-H-TX
< FERRITE BEAD >
FB301 1-414-234-22 FERRITE 0uH
FB302 1-414-234-22 FERRITE 0uH
FB303 1-414-234-22 FERRITE 0uH
< IC >
IC201 8-759-521-35 IC TL5001CDR
IC202 8-759-710-82 IC NJM2406F-TE2
IC301 8-759-364-05 IC MB40D001PFV-G-BND-ER
IC302 8-759-539-27 IC IR3Y37A4
IC401 8-759-587-61 IC LZ9GH234
IC402 8-759-327-01 IC NJM062V(TE2)
< COIL >
L201 1-414-753-91 INDUCTOR 4.7uH
L202 1-424-674-11 INDUCTOR 22uH
L203 1-419-387-21 INDUCTOR 100uH
L301 1-469-528-91 INDUCTOR 100uH
L302 1-469-525-91 INDUCTOR 10uH
L401 1-469-525-91 INDUCTOR 10uH
L402 1-469-525-91 INDUCTOR 10uH
L403 1-469-525-91 INDUCTOR 10uH
L405 1-412-949-21 INDUCTOR 6.8uH
< TRANSISTOR >
Q201 8-729-042-72 TRANSISTOR UN9214J-(K8).SO
Q202 8-729-042-59 TRANSISTOR UN9112J-(K8).SO
Q203 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q204 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q205 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q206 8-729-823-84 TRANSISTOR FP102-TL
Q207 8-729-053-52 TRANSISTOR HN1C01FE-Y/GR(TPLR3)
Q208 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q209 8-729-039-43 TRANSISTOR FP216-TL
Q210 8-729-042-59 TRANSISTOR UN9112J-(K8).SO
Q301 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q401 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q402 8-729-042-26 TRANSISTOR 2SB1462J-QR(K8).SO
Q403 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q404 8-729-042-26 TRANSISTOR 2SB1462J-QR(K8).SO
< RESISTOR >
R203 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R204 1-218-970-11 METAL CHIP 27K 0.5% 1/16W
R205 1-218-978-11 METAL CHIP 120K 0.5% 1/16W
R206 1-218-950-11 RES-CHIP 560 5% 1/16W
R207 1-218-969-11 RES-CHIP 22K 5% 1/16W
PK-58
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
