Sony MVC-CD200 Service Manual

6-26
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R208 1-218-950-11 RES-CHIP 560 5% 1/16W
R209 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R210 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R211 1-208-689-11 METAL CHIP 1.8K 0.5% 1/16W
R212 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R213 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R214 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R215 1-218-973-11 RES-CHIP 47K 5% 1/16W
R216 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R217 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R218 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R219 1-218-977-11 RES-CHIP 100K 5% 1/16W
R220 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R221 1-218-969-11 RES-CHIP 22K 5% 1/16W
R222 1-218-949-11 RES-CHIP 470 5% 1/16W
R223 1-218-942-11 RES-CHIP 120 5% 1/16W
R303 1-218-951-11 RES-CHIP 680 5% 1/16W
R304 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R306 1-218-969-11 RES-CHIP 22K 5% 1/16W
R307 1-218-949-11 RES-CHIP 470 5% 1/16W
R308 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R309 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R310 1-218-990-11 SHORT 0
R311 1-218-969-11 RES-CHIP 22K 5% 1/16W
R312 1-218-966-11 RES-CHIP 12K 5% 1/16W
R313 1-218-973-11 RES-CHIP 47K 5% 1/16W
R316 1-218-967-11 RES-CHIP 15K 5% 1/16W
R317 1-218-971-11 RES-CHIP 33K 5% 1/16W
R318 1-218-966-11 RES-CHIP 12K 5% 1/16W
R319 1-218-972-11 RES-CHIP 39K 5% 1/16W
R320 1-218-977-11 RES-CHIP 100K 5% 1/16W
R321 1-218-965-11 RES-CHIP 10K 5% 1/16W
R322 1-218-985-11 RES-CHIP 470K 5% 1/16W
R323 1-218-985-11 RES-CHIP 470K 5% 1/16W
R403 1-218-990-11 SHORT 0
R404 1-218-973-11 RES-CHIP 47K 5% 1/16W
R405 1-218-973-11 RES-CHIP 47K 5% 1/16W
R408 1-218-987-11 RES-CHIP 680K 5% 1/16W
R409 1-218-978-11 RES-CHIP 120K 5% 1/16W
R410 1-218-977-11 RES-CHIP 100K 5% 1/16W
R411 1-218-965-11 RES-CHIP 10K 5% 1/16W
R412 1-218-989-11 RES-CHIP 1M 5% 1/16W
R414 1-218-989-11 RES-CHIP 1M 5% 1/16W
R415 1-218-969-11 RES-CHIP 22K 5% 1/16W
R416 1-218-975-11 RES-CHIP 68K 5% 1/16W
R417 1-218-975-11 RES-CHIP 68K 5% 1/16W
R418 1-218-973-11 RES-CHIP 47K 5% 1/16W
R419 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R420 1-208-719-11 METAL CHIP 33K 0.5% 1/16W
R421 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R422 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R425 1-218-977-11 RES-CHIP 100K 5% 1/16W
R426 1-218-971-11 RES-CHIP 33K 5% 1/16W
R427 1-218-990-11 SHORT 0
R428 1-218-977-11 RES-CHIP 100K 5% 1/16W
R429 1-218-977-11 RES-CHIP 100K 5% 1/16W
R432 1-218-977-11 RES-CHIP 100K 5% 1/16W
R433 1-218-971-11 RES-CHIP 33K 5% 1/16W
R434 1-218-990-11 SHORT 0
R435 1-208-719-11 METAL CHIP 33K 0.5% 1/16W
R436 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R437 1-208-719-11 METAL CHIP 33K 0.5% 1/16W
R438 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R440 1-218-990-11 SHORT 0
R442 1-218-990-11 SHORT 0
R444 1-218-990-11 SHORT 0
R445 1-218-990-11 SHORT 0
R446 1-218-990-11 SHORT 0
R447 1-218-990-11 SHORT 0
R448 1-218-990-11 SHORT 0
R449 1-218-990-11 SHORT 0
R455 1-218-990-11 SHORT 0
R458 1-218-990-11 SHORT 0
R459 1-218-990-11 SHORT 0
R461 1-218-937-11 RES-CHIP 47 5% 1/16W
R462 1-218-937-11 RES-CHIP 47 5% 1/16W
R463 1-218-937-11 RES-CHIP 47 5% 1/16W
R467 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
< SWITCH >
S301 1-771-138-82 SWITCH, KEY BOARD (DISPLAY)
S303 1-771-138-82 SWITCH, KEY BOARD (AE LOCK)
S304 1-771-138-82 SWITCH, KEY BOARD (SPOT METER)
S305 1-692-088-11 SWITCH, TACTILE (RESET)
S306 1-771-138-82 SWITCH, KEY BOARD (EXPOSURE)
S307 1-771-138-82 SWITCH, KEY BOARD (FOCUS)
< TRANSFORMER >
0 T201 1-435-227-11 TRANSFORMER, INVERTER
**************************************************************
A-7074-837-A TK-61 BOARD, COMPLETE (CD300)
*****************************
A-7074-907-A TK-61 (200) BOARD, COMPLETE (CD200)
*********************************
(Ref.No.;6000 Series)
< CONNECTOR >
CN501 1-766-335-21 CONNECTOR, FFC/FPC 5P
CN503 1-766-335-21 CONNECTOR, FFC/FPC 5P
< TRANSISTOR >
Q501 8-729-427-72 TRANSISTOR HN1C01FU-TE85R
< RESISTOR >
R502 1-218-969-11 RES-CHIP 22K 5% 1/16W
R503 1-218-990-11 SHORT 0
R504 1-218-990-11 SHORT 0
R506 1-218-940-11 RES-CHIP 82 5% 1/16W
R507 1-218-953-11 RES-CHIP 1K 5% 1/16W
R508 1-218-965-11 RES-CHIP 10K 5% 1/16W
R509 1-218-965-11 RES-CHIP 10K 5% 1/16W
R510 1-218-942-11 RES-CHIP 120 5% 1/16W
R511 1-218-990-11 SHORT 0
R512 1-218-990-11 SHORT 0
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
PK-58 TK-61
