– 73 –
< JACK >
* J501 1-537-405-11 TERMINAL BOARD (2P SP)
(SPEAKER OUT R-ch)
* J502 1-750-178-31 JACK, PIN 2P (SIGNAL INPUT)
< CABLE HOLDER >
* KH511 1-565-385-11 HOLDER, CABLE 4P
* KH513 1-573-287-11 HOLDER, CABLE 2P
*************************************************************
* 1-666-186-11 LAMP BOARD
***********
< CABLE HOLDER >
* KH804 1-573-287-11 HOLDER, CABLE 2P
< PILOT LAMP >
PL801 1-517-474-21 LAMP, PILOT
PL802 1-517-474-21 LAMP, PILOT
*************************************************************
* A-3321-474-A LINE BOARD, COMPLETE
********************
< CAPACITOR >
C123 1-162-282-31 CERAMIC 100PF 10% 50V
C125 1-126-964-11 ELECT 10uF 20% 50V
C126 1-126-964-11 ELECT 10uF 20% 50V
C223 1-162-282-31 CERAMIC 100PF 10% 50V
C225 1-126-964-11 ELECT 10uF 20% 50V
C226 1-126-964-11 ELECT 10uF 20% 50V
C318 1-126-963-11 ELECT 4.7uF 20% 50V
C319 1-161-494-00 CERAMIC 0.022uF 25V
C320 1-104-665-11 ELECT 100uF 20% 10V
C321 1-104-664-11 ELECT 47uF 20% 10V
< DIODE >
D321 8-719-991-33 DIODE 1SS133T-77
D322 8-719-991-33 DIODE 1SS133T-77
< IC >
IC304 8-759-634-51 IC M5218AP
J331 8-749-921-12 IC GP1F32T (OPTICAL DIGITAL OUT (CD))
< JACK >
J323 1-566-822-21 JACK (LINE IN)
J332 1-566-822-21 JACK (LINE OUT)
< CABLE HOLDER >
* KH307 1-568-135-21 HOLDER, CABLE 7P
< COIL >
L111 1-412-503-11 INDUCTOR 22uH
L131 1-412-503-11 INDUCTOR 22uH
L211 1-412-503-11 INDUCTOR 22uH
L231 1-412-503-11 INDUCTOR 22uH
L301 1-410-397-21 FERRITE BEAD INDUCTOR 1.1uH
L311 1-412-503-11 INDUCTOR 22uH
L331 1-412-503-11 INDUCTOR 22uH
< TRANSISTOR >
Q101 8-729-900-74 TRANSISTOR DTC143TS
Q104 8-729-900-74 TRANSISTOR DTC143TS
Q201 8-729-900-74 TRANSISTOR DTC143TS
Q204 8-729-900-74 TRANSISTOR DTC143TS
< RESISTOR >
R120 1-249-441-11 CARBON 100K 5% 1/4W
R121 1-249-441-11 CARBON 100K 5% 1/4W
R122 1-247-843-11 CARBON 3.3K 5% 1/4W
R123 1-247-863-00 CARBON 22K 5% 1/4W
R124 1-249-421-11 CARBON 2.2K 5% 1/4W
R125 1-249-421-11 CARBON 2.2K 5% 1/4W
R220 1-249-441-11 CARBON 100K 5% 1/4W
R221 1-249-441-11 CARBON 100K 5% 1/4W
R222 1-247-843-11 CARBON 3.3K 5% 1/4W
R223 1-247-863-00 CARBON 22K 5% 1/4W
R224 1-249-421-11 CARBON 2.2K 5% 1/4W
R225 1-249-421-11 CARBON 2.2K 5% 1/4W
R308 1-249-425-11 CARBON 4.7K 5% 1/4W
R309 1-249-426-11 CARBON 5.6K 5% 1/4W
R321 1-247-807-11 CARBON 100 5% 1/4W
*************************************************************
* 1-671-064-11 POWER BOARD
*************
1-533-233-21 HOLDER, FUSE
< CAPACITOR >
C501 1-101-005-00 CERAMIC 0.022uF 50V
C502 1-136-169-00 FILM 0.22uF 5% 50V
C503 1-136-169-00 FILM 0.22uF 5% 50V
C504 1-101-005-00 CERAMIC 0.022uF 50V
C505 1-136-169-00 FILM 0.22uF 5% 50V
< CONNECTOR >
CNP501 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
D501 8-719-902-17 DIODE U15G
D502 8-719-902-17 DIODE U15G
D503 8-719-902-17 DIODE U15G
D504 8-719-902-17 DIODE U15G
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
POWER
LINEJACK
LAMP
