– 74 –
< FUSE >
! F501 1-532-505-31 FUSE, TIME-LAG (T5A/250V)
< TRANSFORMER >
! FL501 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< CABLE HOLDER >
* KH505 1-573-287-11 HOLDER, CABLE 2P
*************************************************************
* 1-662-742-11 SW BOARD
*********
< CONNECTOR >
* CN691 1-564-725-11 PIN, CONNECTOR (SMALL TYPE) 9P
< PHOTO REFLECTOR >
PH691 1-801-455-11 PHOTO REFLECTOR
< RESISTOR >
R691 1-247-827-11 CARBON 680 5% 1/4W
< SWITCH >
S691 1-762-811-11 SWITCH, LEAF (HALF (CASSETTE))
S694 1-762-811-11 SWITCH, LEAF (REC-REV (ERASE PROOF))
S695 1-762-811-11 SWITCH, LEAF (REC-FWD (ERASE PROOF))
S696 1-762-810-11 SWITCH, LEAF (MODE (HEAD POSITION))
*************************************************************
* 1-666-184-11 SW (A) BOARD
************
< CAPACITOR >
C902 1-162-282-31 CERAMIC 100PF 10% 50V
C903 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CNP901 1-770-398-11 HOUSING, CONNECTOR (PC BOARD) 5P
CNP902 1-770-396-11 HOUSING, CONNECTOR (PC BOARD) 3P
< IC >
IC901 8-759-471-49 IC NJL57H400A
< CABLE HOLDER >
* KH903 1-573-287-11 HOLDER, CABLE 2P
< RESISTOR >
R950 1-249-415-11 CARBON 680 5% 1/4W
R951 1-249-416-11 CARBON 820 5% 1/4W
R952 1-249-418-11 CARBON 1.2K 5% 1/4W
R953 1-249-420-11 CARBON 1.8K 5% 1/4W
R954 1-247-843-11 CARBON 3.3K 5% 1/4W
R955 1-249-427-11 CARBON 6.8K 5% 1/4W
R956 1-249-415-11 CARBON 680 5% 1/4W
R957 1-249-416-11 CARBON 820 5% 1/4W
R958 1-249-418-11 CARBON 1.2K 5% 1/4W
R959 1-249-420-11 CARBON 1.8K 5% 1/4W
R960 1-247-843-11 CARBON 3.3K 5% 1/4W
R961 1-249-427-11 CARBON 6.8K 5% 1/4W
R962 1-249-415-11 CARBON 680 5% 1/4W
R963 1-249-416-11 CARBON 820 5% 1/4W
R964 1-249-418-11 CARBON 1.2K 5% 1/4W
R965 1-249-420-11 CARBON 1.8K 5% 1/4W
R966 1-247-843-11 CARBON 3.3K 5% 1/4W
R967 1-249-427-11 CARBON 6.8K 5% 1/4W
< SWITCH >
S901 1-692-014-11 SWITCH, KEY BOARD ())
S902 1-692-014-11 SWITCH, KEY BOARD (0)
S903 1-692-014-11 SWITCH, KEY BOARD (( (TAPE))
S904 1-692-014-11 SWITCH, KEY BOARD (p (TAPE))
S905 1-692-014-11 SWITCH, KEY BOARD (9 (TAPE))
S906 1-692-014-11 SWITCH, KEY BOARD (r/P (TAPE))
S907 1-692-014-11 SWITCH, KEY BOARD (DIR MODE)
S908 1-692-014-11 SWITCH, KEY BOARD (p (CD))
S909 1-692-014-11 SWITCH, KEY BOARD (P (CD))
S910 1-692-014-11 SWITCH, KEY BOARD (( (CD))
S911 1-692-014-11 SWITCH, KEY BOARD (FUNCTION)
S912 1-692-014-11 SWITCH, KEY BOARD (OPERATE)
S913 1-692-014-11 SWITCH, KEY BOARD (DISPLAY/ENTER)
S914 1-692-014-11 SWITCH, KEY BOARD (VOLUME +)
S915 1-692-014-11 SWITCH, KEY BOARD (VOLUME –)
S916 1-692-014-11 SWITCH, KEY BOARD (+/TUNE –)
S917 1-692-014-11 SWITCH, KEY BOARD (=/TUNE +)
S918 1-692-014-11 SWITCH, KEY BOARD (BAND (RADIO))
S919 1-692-014-11 SWITCH, KEY BOARD (PRESET + (RADIO))
S920 1-692-014-11 SWITCH, KEY BOARD (PRESET – (RADIO))
************************************************************
* 1-666-185-11 SW (B) BOARD
************
< CABLE HOLDER >
* KH904 1-573-287-11 HOLDER, CABLE 2P
< RESISTOR >
R970 1-249-415-11 CARBON 680 5% 1/4W
R971 1-249-416-11 CARBON 820 5% 1/4W
< SWITCH >
S921 1-692-014-11 SWITCH, KEY BOARD (SOUND)
S922 1-692-014-11 SWITCH, KEY BOARD (PGM SET/AUTO PRESET)
S923 1-692-014-11 SWITCH, KEY BOARD
(PLAY MODE MONO/ST/ISS)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
POWER
The components identified b y
mark ! or dotted line with mark.
! are cr itical for saf ety.
Replace only with part number
specified.
SW SW (A) SW (B)
To Next Page
