– 75 –
* 1-671-066-11 TERMINAL BOARD
***************
< CAPACITOR >
C284 1-130-495-00 MYLAR 0.1uF 5% 50V
C285 1-130-495-00 MYLAR 0.1uF 5% 50V
C381 1-126-946-11 ELECT 6800uF 20% 25V
< CONNECTOR >
* CNP503 1-506-946-11 PIN, CONNECTOR 4P
* CNP504 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CNP505 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< CABLE HOLDER >
* KH510 1-565-385-11 HOLDER, CABLE 4P
* KH512 1-573-287-11 HOLDER, CABLE 2P
< FERRITE BEAD >
L501 1-410-397-21 FERRITE BEAD INDUCTOR 1.1uH
< RESISTOR >
! R283 1-249-385-11 CARBON 2.2 5% 1/6W F
! R284 1-249-385-11 CARBON 2.2 5% 1/6W F
*************************************************************
* A-3321-478-A TUNER BOARD, COMPLETE (EXCEPT IT,EE)
* A-3321-479-A TUNER BOARD, COMPLETE (IT)
* A-3321-488-A TUNER BOARD, COMPLETE (EE)
**********************
< CAPACITOR >
C1 1-162-306-11 CERAMIC 0.01uF 20% 16V
C2 1-162-294-31 CERAMIC 0.001uF 10% 50V
C3 1-162-306-11 CERAMIC 0.01uF 20% 16V
C4 1-130-483-00 MYLAR 0.01uF 5% 50V
C6 1-162-306-11 CERAMIC 0.01uF 20% 16V
C7 1-162-282-31 CERAMIC 100PF 10% 50V
C8 1-162-306-11 CERAMIC 0.01uF 20% 16V
C9 1-162-306-11 CERAMIC 0.01uF 20% 16V
C10 1-162-306-11 CERAMIC 0.01uF 20% 16V
C11 1-104-665-11 ELECT 100uF 20% 10V
C12 1-126-963-11 ELECT 4.7uF 20% 50V
C13 1-162-215-31 CERAMIC 47PF 5% 50V
C15 1-162-306-11 CERAMIC 0.01uF 20% 16V
C16 1-162-306-11 CERAMIC 0.01uF 20% 16V
C17 1-162-306-11 CERAMIC 0.01uF 20% 16V
C18 1-161-057-00 CERAMIC 0.033uF 10% 50V
C19 1-161-057-00 CERAMIC 0.033uF 10% 50V
C20 1-126-964-11 ELECT 10uF 20% 50V
C21 1-126-964-11 ELECT 10uF 20% 50V
C22 1-162-850-11 CERAMIC 0.082uF 10% 16V
C23 1-162-849-11 CERAMIC 0.068uF 10% 16V
C24 1-162-850-11 CERAMIC 0.082uF 10% 16V
C25 1-126-964-11 ELECT 10uF 20% 50V
C26 1-162-288-31 CERAMIC 330PF 10% 50V
C29 1-162-286-21 CERAMIC 220PF 10% 50V
C30 1-162-290-31 CERAMIC 470PF 10% 50V
C31 1-126-964-11 ELECT 10uF 20% 50V
C32 1-162-294-31 CERAMIC 0.001uF 10% 50V
C33 1-161-494-00 CERAMIC 0.022uF 25V
C40 1-102-518-11 CERAMIC 33PF 5% 50V
C41 1-162-203-31 CERAMIC 15PF 5% 50V
C42 1-162-306-11 CERAMIC 0.01uF 20% 16V
C43 1-162-282-31 CERAMIC 100PF 10% 50V
C44 1-162-306-11 CERAMIC 0.01uF 20% 16V
C45 1-162-306-11 CERAMIC 0.01uF 20% 16V
C46 1-162-306-11 CERAMIC 0.01uF 20% 16V
C47 1-162-306-11 CERAMIC 0.01uF 20% 16V
C48 1-162-294-31 CERAMIC 0.001uF 10% 50V
C49 1-162-294-31 CERAMIC 0.001uF 10% 50V
C50 1-162-294-31 CERAMIC 0.001uF 10% 50V
C51 1-162-306-11 CERAMIC 0.01uF 20% 16V
C52 1-126-964-11 ELECT 10uF 20% 50V
C53 1-162-306-11 CERAMIC 0.01uF 20% 16V
C54 1-126-964-11 ELECT 10uF 20% 50V
C55 1-136-177-00 FILM 1uF 5% 50V
C56 1-162-306-11 CERAMIC 0.01uF 20% 16V
C60 1-161-772-11 CERAMIC 0.1uF 10% 25V
C61 1-162-291-31 CERAMIC 560PF 10% 50V
C62 1-162-207-31 CERAMIC 22PF 5% 50V
C63 1-161-772-11 CERAMIC 0.1uF 10% 25V
C64 1-162-306-11 CERAMIC 0.01uF 20% 16V
C65 1-162-306-11 CERAMIC 0.01uF 20% 16V
C66 1-130-495-00 MYLAR 0.1uF 5% 50V
C69 1-161-494-00 CERAMIC 0.022uF 25V
C70 1-136-356-11 FILM 470PF 5% 63V
C72 1-162-282-31 CERAMIC 100PF 10% 50V
C73 1-162-306-11 CERAMIC 0.01uF 20% 16V
C74 1-162-306-11 CERAMIC 0.01uF 20% 16V
C75 1-162-281-31 CERAMIC 91PF 10% 50V
C76 1-162-306-11 CERAMIC 0.01uF 20% 16V
C84 1-162-306-11 CERAMIC 0.01uF 20% 16V
C88 1-162-306-11 CERAMIC 0.01uF 20% 16V
C90 1-162-282-31 CERAMIC 100PF 10% 50V
C91 1-162-282-31 CERAMIC 100PF 10% 50V
C93 1-162-306-11 CERAMIC 0.01uF 20% 16V
C95 1-162-282-31 CERAMIC 100PF 10% 50V
C96 1-162-294-31 CERAMIC 0.001uF 10% 50V
C99 1-162-294-31 CERAMIC 0.001uF 10% 50V
< FILTER >
CF1 1-767-557-11 FILTER, CERAMIC
CF2 1-767-557-11 FILTER, CERAMIC
CF3 1-767-557-11 FILTER, CERAMIC
CF4 1-767-096-11 VIBRATOR, CERAMIC
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TUNER
TERMINAL
The components identified b y
mark ! or dotted line with mark.
! are cr itical for saf ety.
Replace only with part number
specified.
To Next Page
