< ENCAPSULATED COMPONENT >
CFT1 1-239-173-11 ENCAPSULATED COMPONENT
< CONNECTOR >
CNP1 1-778-310-11 PLUG, CONNECTOR 2P (MW/LW)
CNP2 1-779-535-11 CONNECTOR, COAXIAL (EXT ANT FM)
CNP3 1-573-844-11 CONNECTOR, BOARD TO BOARD 12P
< TRIMMER >
CT4 1-141-410-11 CAP, ADJ 10PF
CT5 1-141-439-21 CAP, ADJ 40PF
< DIODE >
D5 8-719-976-30 DIODE KV1560N
D90 8-719-991-33 DIODE 1SS133T-77
D91 8-719-991-33 DIODE 1SS133T-77
D92 8-719-991-33 DIODE 1SS133T-77
D93 8-719-991-33 DIODE 1SS133T-77
D94 8-719-991-33 DIODE 1SS133T-77
D95 8-719-991-33 DIODE 1SS133T-77
< IC >
IC1 8-759-386-02 IC TA2008AN
IC2 8-759-290-61 IC BU2615S
< COIL >
L3 1-416-248-11 COIL, MW RF
L4 1-416-247-11 COIL (OSC)
L5 1-416-249-11 COIL, LW RF
L6 1-412-514-11 INDUCTOR 220uH
L40 1-412-514-11 INDUCTOR 220uH
< TRANSISTOR >
Q1 8-729-905-50 TRANSISTOR DTC343TS
Q2 8-729-905-50 TRANSISTOR DTC343TS
Q3 8-729-922-66 TRANSISTOR 2SC2410SN
Q4 8-729-922-66 TRANSISTOR 2SC2410SN
Q5 8-729-178-62 TRANSISTOR 2SC2786-L
Q6 8-729-119-32 FET 2SK193
Q7 8-729-922-66 TRANSISTOR 2SC2410SN
Q8 8-729-904-39 TRANSISTOR DTC114TS
Q9 8-729-115-80 TRANSISTOR BA1A4P
Q10 8-729-115-80 TRANSISTOR BA1A4P
Q11 8-729-115-80 TRANSISTOR BA1A4P
Q12 8-729-115-80 TRANSISTOR BA1A4P
Q13 8-729-012-83 FET 2SK679A
Q17 8-729-029-23 TRANSISTOR DTA114TSA-TP
Q21 8-729-422-57 TRANSISTOR UN4111
Q22 8-729-422-57 TRANSISTOR UN4111
Q24 8-729-422-57 TRANSISTOR UN4111
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< RESISTOR >
R1 1-249-417-11 CARBON 1K 5% 1/4W
R2 1-249-411-11 CARBON 330 5% 1/4W
R3 1-247-791-00 CARBON 22 5% 1/4W
R10 1-249-403-11 CARBON 68 5% 1/4W
R11 1-249-425-11 CARBON 4.7K 5% 1/4W
R13 1-249-407-11 CARBON 150 5% 1/4W
R14 1-249-437-11 CARBON 47K 5% 1/4W
R15 1-249-393-11 CARBON 10 5% 1/4W
R16 1-247-807-11 CARBON 100 5% 1/4W
R17 1-249-421-11 CARBON 2.2K 5% 1/4W
R18 1-249-393-11 CARBON 10 5% 1/4W
R19 1-247-863-00 CARBON 22K 5% 1/4W
R21 1-247-863-00 CARBON 22K 5% 1/4W
R22 1-249-421-11 CARBON 2.2K 5% 1/4W
R23 1-249-421-11 CARBON 2.2K 5% 1/4W
R25 1-249-425-11 CARBON 4.7K 5% 1/4W
R26 1-249-425-11 CARBON 4.7K 5% 1/4W
R27 1-249-425-11 CARBON 4.7K 5% 1/4W
R28 1-249-425-11 CARBON 4.7K 5% 1/4W
R29 1-249-421-11 CARBON 2.2K 5% 1/4W
R30 1-249-441-11 CARBON 100K 5% 1/4W
R40 1-249-429-11 CARBON 10K 5% 1/4W
R41 1-249-429-11 CARBON 10K 5% 1/4W
R42 1-249-429-11 CARBON 10K 5% 1/4W
R43 1-249-429-11 CARBON 10K 5% 1/4W
R44 1-249-417-11 CARBON 1K 5% 1/4W
R45 1-249-417-11 CARBON 1K 5% 1/4W
R46 1-249-417-11 CARBON 1K 5% 1/4W
R47 1-249-417-11 CARBON 1K 5% 1/4W
R49 1-249-412-11 CARBON 390 5% 1/4W
R50 1-249-415-11 CARBON 680 5% 1/4W
R51 1-249-417-11 CARBON 1K 5% 1/4W
R52 1-249-427-11 CARBON 6.8K 5% 1/4W
R53 1-247-863-00 CARBON 22K 5% 1/4W
R54 1-249-417-11 CARBON 1K 5% 1/4W
R55 1-249-437-11 CARBON 47K 5% 1/4W
R56 1-249-437-11 CARBON 47K 5% 1/4W
R57 1-249-437-11 CARBON 47K 5% 1/4W
R59 1-247-843-11 CARBON 3.3K 5% 1/4W
R60 1-249-429-11 CARBON 10K 5% 1/4W
R61 1-249-425-11 CARBON 4.7K 5% 1/4W
R62 1-249-425-11 CARBON 4.7K 5% 1/4W
R63 1-249-441-11 CARBON 100K 5% 1/4W
R64 1-247-887-00 CARBON 220K 5% 1/4W
R65 1-249-411-11 CARBON 330 5% 1/4W
R66 1-249-413-11 CARBON 470 5% 1/4W
R67 1-249-429-11 CARBON 10K 5% 1/4W
R70 1-249-425-11 CARBON 4.7K 5% 1/4W
R71 1-249-425-11 CARBON 4.7K 5% 1/4W
R72 1-249-425-11 CARBON 4.7K 5% 1/4W
R73 1-247-887-00 CARBON 220K 5% 1/4W
TUNER
