Item2 (Display block diagnosis)
The display block diagnosis tests the following contents.
ID Diagnosis Error value Type1/2 Note
0x01 Communication signal line test of COPRO
(SAD)
-1: Connection error 1, 2 —
0x02 Communication signal line test of LCD
(SAD)
-1: Connection error 1, 2 —
0x03 Communication signal line test of IO Ex-
pander (SAD)
-1: Connection error 1, 2 —
Item3 (Media block diagnosis)
The media block diagnosis tests the following contents. An error value of "-6" is displayed in some cases with any ID
other than the following IDs, but this is not a problem.
Be sure to turn off the power after Item3 has been executed.
ID Intended device Diagnosis Error value Type1/2 Note
0x01 — Command response on-
ly
Normal end "0" is always
returned.
2 Startup must be com-
pleted
0x06 USB Device Register Read/Write Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x08 USB Device Read/Write Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x09 i.LINK Register Read/Write Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x0A i.LINK Read/Write Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x0B USB Host Register Read/Write Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x0D USB Host Read/Write Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x11 TK-1(SlotA) Data Read/Write Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x12 Torino Data Read/Write Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x13 TK-1(SlotB) Data Read/Write Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x14 PIFC POWSW Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x15 SPA POWSW Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x16 NATH Data Read/Write Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x20 NOR-FlashROM NOR-Flash ROM data
matching check
Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x21 ExpressCard ExpressCard power
switch ON/OFF control
Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x22 (SlotA) ExpressCard overcur-
rent detection
Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x23 LED LED blink check Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x24 LED LED blink check Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
Continued
PMW-300
3-8
