ID Intended device Diagnosis Error value Type1/2 Note
0x25 ExpressCard ExpressCard power
switch ON/OFF control
Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x26 (SlotB) ExpressCard overcur-
rent detection
Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x30 Torino (Video sig-
nal line)
Video encoding Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x31 Torino (Audio sig-
nal line)
Audio encoding Non-installation "-6" is al-
ways returned.
1 Startup must be com-
pleted
0x32 4-bit signal line Transfer data (from
Ramiel) check
Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x35 NATH (Video sig-
nal line )
Video encoding Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
0x36 NATH (Audio sig-
nal line )
Audio encoding Refer to "Details of diag-
nosis"
1 Startup must be com-
pleted
Details of diagnosis
Error value Diagnosis
0 Normal end
-1 Hardware error detected
-4 Service tool not detected
-6 Non-installation
Item4 (Audio block diagnosis)
The audio block diagnosis tests the following content.
ID Diagnosis Error value Type1/2 Note
0x11 Audio memory area check (in the
CXD9211CGG (Main T-one))
-1: Memory read/write comparison
error
1, 2 —
0x12 FPGA (ANDC) access check
(AU-357 board IC501 A6 pin, A4
pin, A7 pin, A5 pin)
-1: Register set value acquisition er-
ror
1, 2 —
0x13
DSP-only DPSRAM check Other than 0: DPSRAM check error 1, 2 —
Error number of failed diagnosis is
displayed as an error value. For error
values, refer to "Error values of di-
agnosis items ID 0x13".
0x14
Serial audio data check in the audio
block
Other than 0: Mismatch between out-
put data and input data
1, 2 —
Error number of failed diagnosis is
displayed as an error value. For error
values, refer to "Error values of di-
agnosis items ID 0x14".
0x15
Serial audio data reception check of
IC1700 on the DCP-64 board
Other than 0: Mismatch between out-
put data and input data
1, 2 —
Error number of failed diagnosis is
displayed as an error value. For error
values, refer to "Error values of di-
agnosis items ID 0x15".
PMW-300
3-9
