Sony RCD-W1 - IC Pin Function Descriptions (Continued); IC801 Pin Functions (Continued)

54
RCD-W1
Pin No. Pin Name I/O
Description
51 F27 O Fluoresent disply tube segment signal output.
52 F26 O Fluoresent disply tube segment signal output.
53 F25 O Fluoresent disply tube segment signal output.
54 F24 O Fluoresent disply tube segment signal output.
55 F23 O Fluoresent disply tube segment signal output.
56 F22 O Fluoresent disply tube segment signal output.
57 F21 O Fluoresent disply tube segment signal output.
58 F20 O Fluoresent disply tube segment signal output.
59 VDD2 I Power supply for FL driver
60 VLOAD I Power supply (-34V) for FL driver
61 F19 O Fluoresent disply tube segment signal output.
62 F18 O Fluoresent disply tube segment signal output.
63 F17 O Fluoresent disply tube segment signal output.
64 F16 O Fluoresent disply tube segment signal output.
65 F15 O Fluoresent disply tube common signal output.
66 F14 O Fluoresent disply tube common signal output.
67 F13 O Fluoresent disply tube common signal output.
68 F12 O Fluoresent disply tube common signal output.
69 F11 O Fluoresent disply tube common signal output.
70 F10 O Fluoresent disply tube common signal output.
71 F9 O Fluoresent disply tube common signal output.
72 F8 O Fluoresent disply tube common signal output.
73 F7 O Fluoresent disply tube common signal output.
74 F6 O Fluoresent disply tube common signal output.
75 F5 O Fluoresent disply tube common signal output.
76 F4 O Fluoresent disply tube common signal output.
77 F3 O Fluoresent disply tube common signal output.
78 F2 O Fluoresent disply tube common signal output.
79 F1 O Fluoresent disply tube common signal output.
80 F0 O Fluoresent disply tube common signal output.
