Sony RCD-W3 Service Manual

64
RCD-W3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HP
< CAPACITOR >
C801 1-164-159-11 CERAMIC 0.1uF 50V
C802 1-164-159-11 CERAMIC 0.1uF 50V
C804 1-126-933-11 ELECT 100uF 20% 16V
C805 1-161-494-00 CERAMIC 0.022uF 25V
C806 1-161-494-00 CERAMIC 0.022uF 25V
C807 1-161-494-00 CERAMIC 0.022uF 25V
C810 1-164-159-11 CERAMIC 0.1uF 50V
C811 1-162-282-31 CERAMIC 100PF 10% 50V
C812 1-162-282-31 CERAMIC 100PF 10% 50V
C813 1-162-282-31 CERAMIC 100PF 10% 50V
C816 1-162-211-31 CERAMIC 33PF 5% 50V
C817 1-162-211-31 CERAMIC 33PF 5% 50V
C818 1-164-159-11 CERAMIC 0.1uF 50V
C820 1-164-159-11 CERAMIC 0.1uF 50V
C821 1-164-159-11 CERAMIC 0.1uF 50V
C822 1-164-159-11 CERAMIC 0.1uF 50V
C823 1-164-159-11 CERAMIC 0.1uF 50V
C826 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN801 1-779-288-11 CONNECTOR, FFC(LIF(NON-ZIF))20P
CN803 1-816-678-11 CONNECTOR (BOARD TO BOARD) 8P
< FLUORESCENT INDICATOR TUBE >
FLD801 1-518-830-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 6-800-228-01 IC uPD780232GC-LG1
IC802 8-759-971-11 IC KIA7042P-TP
< RESISTOR >
R803 1-247-843-11 CARBON 3.3K 5% 1/4W
R804 1-249-424-11 CARBON 3.9K 5% 1/4W F
R807 1-249-420-11 CARBON 1.8K 5% 1/4W F
R808 1-249-422-11 CARBON 2.7K 5% 1/4W F
R809 1-247-843-11 CARBON 3.3K 5% 1/4W
R810 1-249-424-11 CARBON 3.9K 5% 1/4W F
R811 1-249-426-11 CARBON 5.6K 5% 1/4W
R812 1-249-428-11 CARBON 8.2K 5% 1/4W F
R813 1-249-420-11 CARBON 1.8K 5% 1/4W F
R814 1-249-422-11 CARBON 2.7K 5% 1/4W F
R815 1-247-843-11 CARBON 3.3K 5% 1/4W
R816 1-249-424-11 CARBON 3.9K 5% 1/4W F
R817 1-249-426-11 CARBON 5.6K 5% 1/4W
R818 1-249-428-11 CARBON 8.2K 5% 1/4W F
R819 1-249-431-11 CARBON 15K 5% 1/4W
R833 1-247-807-31 CARBON 100 5% 1/4W
R834 1-247-843-11 CARBON 3.3K 5% 1/4W
R841 1-249-425-11 CARBON 4.7K 5% 1/4W F
R842 1-249-417-11 CARBON 1K 5% 1/4W F
R843 1-249-417-11 CARBON 1K 5% 1/4W F
R844 1-249-417-11 CARBON 1K 5% 1/4W F
R845 1-249-417-11 CARBON 1K 5% 1/4W F
R847 1-249-437-11 CARBON 47K 5% 1/4W
R848 1-249-437-11 CARBON 47K 5% 1/4W
R849 1-249-437-11 CARBON 47K 5% 1/4W
R850 1-249-437-11 CARBON 47K 5% 1/4W
R851 1-249-437-11 CARBON 47K 5% 1/4W
< RECEIVER >
RMC801 8-749-016-29 IC RPM6938
< SWITCH >
SW803 1-572-184-11 SWITCH, KEYBOARD (AMS >)
SW804 1-572-184-11 SWITCH, KEYBOARD (AMS .)
SW808 1-572-184-11 SWITCH, KEYBOARD (CD SYNCHRO NORMAL)
SW810 1-572-184-11 SWITCH, KEYBOARD (INPUT)
SW811 1-572-184-11 SWITCH, KEYBOARD (CD SYNCHRO HIGH)
SW812 1-572-184-11 SWITCH, KEYBOARD (ERASE)
SW813 1-572-184-11 SWITCH, KEYBOARD (FINALIZE)
SW814 1-572-184-11 SWITCH, KEYBOARD (LEVEL SYNC)
SW815 1-572-184-11 SWITCH, KEYBOARD (OPEN/CLOSE A)
SW816 1-572-184-11 SWITCH, KEYBOARD (TIME)
SW817 1-572-184-11 SWITCH, KEYBOARD (AMS .)
SW818 1-572-184-11 SWITCH, KEYBOARD (AMS >)
SW819 1-572-184-11 SWITCH, KEYBOARD (RELAY)
SW820 1-572-184-11 SWITCH, KEYBOARD (X)
SW821 1-572-184-11 SWITCH, KEYBOARD (G)
SW822 1-572-184-11 SWITCH, KEYBOARD (x)
< VIBRATOR >
X801 1-795-348-11 VIBRATOR, CRYSTAL (5MHz)
******************************************************
HP BOARD
********
< FERRITE BEAD >
BD801 1-400-104-11 INDUCTOR, FERRITE BEAD 0
BD802 1-400-104-11 INDUCTOR, FERRITE BEAD 0
BD803 1-400-104-11 INDUCTOR, FERRITE BEAD 0
< JACK >
JK802 1-815-702-11 JACK (LARGE TYPE) (PHONES)
< CONNECTOR >
* PN902 1-568-226-11 PIN, CONNECTOR(3.96MM PITCH)2P
< SWITCH >
PW801 1-771-757-12 SWITCH, PUSH (1 KEY) (POWER)
< RESISTOR >
R8H1 1-216-790-11 METAL CHIP 2.7 5% 1/16W
R8H2 1-216-790-11 METAL CHIP 2.7 5% 1/16W
< VARIABLE RESISTOR >
VR801 1-227-425-11 RES, VAR, CARBON 50K/50K (PHONE LEVEL)
******************************************************
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
FL

Sony RCD-W3 Specifications

Power

power requirements	U.S.A. and Canada 120 V AC, 60 Hz
power requirements other countries	110 – 240 V AC, 50/60 Hz
power consumption	20 W

Audio Specifications

frequency response	20 Hz – 20, 000 Hz (±0.5 dB)
signal-to-noise ratio	More than 100 dB
dynamic range	More than 95 dB

Inputs

analog in impedance	47 kilohms
rated input	330 mVrms
minimum input	125 mVrms

Outputs

analog out rated output	2 Vrms (at 50 kilohms)
load impedance	over 10 kilohms
phones	28 mW, 32 ohms

Weight and Dimensions

dimensions	430 × 108 × 368 mm
mass	4.6 kg
