Sony RCD-W3 Service Manual

65
RCD-W3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4731-043-A POWER BOARD, COMPLETE (US,CND)
A-4731-046-A POWER BOARD, COMPLETE (AEP,UK)
*********************
Note:Parts with no description are out of service.
7-685-545-14 SCREW +BTP 3X6 TYPE2 N-S
< BRIDGE DIODE >
0 BD101 8-719-510-06 DIODE S1WB60
< CAPACITOR >
0 C103 1-165-878-11 ELECT 150uF 250V
(US,CND)
0 C103 1-165-879-11 CAP, ELECT 100uF 400V
(AEP,UK)
< DIODE >
0 D102 8-719-085-16 DIODE EU01W
D106 8-719-085-17 DIODE B10A45VI
D107 8-719-085-16 DIODE EU01W
D108 8-719-085-16 DIODE EU01W
D110 8-719-085-15 DIODE RU3YXLF-C1
D120 8-719-085-16 DIODE EU01W
< IC >
0IC101 6-700-520-01 IC STR-G6153T
0IC102 6-700-521-01 PHOTO COUPLER PS2561-1-V
IC104 6-700-522-01 IC KIA431
IC105 8-759-574-75 IC KA78R33TU
IC106 8-759-245-81 IC TA79008S
IC107 8-759-231-55 IC TA7808S
< TRANSFORMER >
0 PT101 1-437-810-11 TRANSFORMER, POWER
< RESISTOR >
0 R101 1-244-389-11 METAL 2.7 2W
< ZENER DIODE >
ZD101 8-719-109-85 DIODE MTZJ-5.1B
******************************************************
VOL BOARD
*********
< CONNECTOR >
* PN803 1-695-822-11 CONNECTOR, BOARD TO BOARD 8P
< RESISTOR >
R801 1-249-420-11 CARBON 1.8K 5% 1/4W F
R802 1-249-422-11 CARBON 2.7K 5% 1/4W F
R805 1-249-426-11 CARBON 5.6K 5% 1/4W
R806 1-249-428-11 CARBON 8.2K 5% 1/4W F
< SWITCH >
SW801 1-572-184-11 SWITCH, KEYBOARD (OPEN/CLOSE A)
SW802 1-572-184-11 SWITCH, KEYBOARD (REC z)
SW805 1-572-184-11 SWITCH, KEYBOARD (X )
SW806 1-572-184-11 SWITCH, KEYBOARD (G)
SW807 1-572-184-11 SWITCH, KEYBOARD (x)
< VARIABLE RESISTOR >
VR802 1-223-799-11 RES, VAR, CARBON 20K/20K (REC LEVEL)
******************************************************
MISCELLANEOUS
*************
11 1-824-266-11 WIRE (FLAT TYPE) (20 CORE)
0 54 1-823-044-11 CORD, POWER (US,CND)
0 54 1-824-779-11 CORD, POWER (UK)
0 54 1-824-780-11 CORD, POWER (AEP)
57 1-824-264-11 WIRE (FLAT TYPE) (30 CORE)
58 1-824-782-11 WIRE (FLAT TYPE) (22 CORE)
0 511 1-476-791-11 OPTICAL PICK-UP BLOCK
512 1-824-781-11 WIRE (FLAT TYPE) (17 CORE)
564 1-823-046-11 WIRE (FLAT TYPE) (32 CORE)
0 F101 1-532-503-51 FUSE (1.6A 250V) (US,CND)
0 F101 1-533-467-11 FUSE, GLASS TUBE (DIA. 5) (T1.6AL 250V)
(AEP,UK)
******************************************************
ACCESSORIES
***********
1-476-514-11 REMOTE COMMANDER (RM-R50)
1-790-735-12 CORD, CONNECTION
4-228-696-01 COVER, BATTERY (For RM-R50)
4-243-586-01 MANUAL ASSY (ENGLISH) (US)
4-243-587-01 MANUAL ASSY (ENGLISH,FRENCH) (CND)
4-243-589-01 MANUAL ASSY(ENGLISH,FRENCH,GERMAN,
DUTCH,SWEDISH,SPANISH,ITALIAN,
PORTUGUESE)(AEP)
4-243-590-01 MANUAL ASSY (ENGLISH) (UK)
