Setup Menu
<OUTPUT
FORMAT>
S04
SLOT NO
1-1&2
SDI OUTPUT
1/2 connector
output format
selection
Sequence of
format options:
1: HD
2: SD
When CAMERA FORMAT
is 1080/59.94i:
1080/59.94i, 525/59.94i
When CAMERA FORMAT
is 720/59.94P: 720/59.94P,
525/59.94i
When CAMERA FORMAT
is 1080/50i: 1080/50i,
625/50i
When CAMERA FORMAT
is 720/50P: 720/50P,
625/50i
Note
The default setting is
different among the
sales areas.
United States and
Canada: 1080/59.94i
Other areas: 1080/50i
3&4
SDI OUTPUT
3/4 connector
output format
selection
Sequence of
format options:
1: HD
2: SD
When CAMERA FORMAT
is 1080/59.94i:
M1080/59.94i,
M525/59.94i
When CAMERA FORMAT
is 720/59.94P:
M720/59.94P, M525/59.94i
When CAMERA FORMAT
is 1080/50i: M1080/50i,
M625/50i
When CAMERA FORMAT
is 720/50P: M720/50P,
M625/50i
Note
The default setting is
different among the
sales areas.
United States and
Canada: M525/59.94i
Other areas: M625/50i
COMPONENT
Component signal
connector output
format selection
HD RGB, HD YPbPr,
SD RGB, SD YCD
HD-SD DELAY
HD signal to SD
signal delay mode
selection
When CAMERA FORMAT
is 1080 system format:
0-Delay
, Line (90H), Frame
(1F)
When CAMERA FORMAT
is 720 system format:
0-Delay, Line (120H),
Frame (2F)
When GENLOCK is HD:
0
to –71.1 µs
When GENLOCK is SD:
0
to –51.7 µs
Page name
Page No.
Item Settings
<SD ASPECT>
S05
SD ASPECT
SD output aspect
selection
SQUEEZE, EDGE CROP,
LETTER BOX
SD LB SEL
LETTER BOX
aspect ratio
selection
16:9
, 15:9, 14:9, 13:9
H POSITION
Horizontal
position setting
–99 to 99, (–99) to (99) 0
( ) displayed when SD
ASPECT is SQUEEZE
or LETTER BOX (read
only)
CENTER
Horizontal
centering
selection
ON
, OFF, (ON), (OFF)
( ) displayed when SD
ASPECT is SQUEEZE
or LETTER BOX (read
only)
V POSITION
Vertical position
setting
–99 to 99, (–99) to (99) (0)
( ) displayed when SD
ASPECT is SQUEEZE
or EDGE CROP (read
only)
CENTER
Ver tical
centering
selection
ON, OFF, (ON)
, (OFF)
( ) displayed when SD
ASPECT is SQUEEZE
or EDGE CROP (read
only)
H INTERP
Down converter
horizontal filter
selection
A
, B, C, D, E
V INTERP
Down converter
vertical filter
selection
A
, B, C, D, E
