Setup Menu
HXCU-100
4-140-418-12 (1)
<RETURN
FORMAT>
S06
The RET1 to 4
signal outputs
support 16
combinations.
See “Return
Signal
Combinations”
on page 29.
RET1
Return 1 signal
format, aspect,
and letterbox
aspect ratio
selection
Sequence of
format options:
1: HD SDI
2: SD SDI
3: VBS
When CAMERA FORMAT
is 1080/59.94i:
1080/59.94i
, 525/59.94i,
NTSC
When CAMERA FORMAT
is 720/59.94P: 720/59.94P,
525/59.94i, NTSC
When CAMERA FORMAT
is 1080/50i: 1080/50i,
625/50i, PAL
When CAMERA FORMAT
is 720/50P: 720/50P,
625/50i, PAL
SQUEEZE, EDGE CROP,
LETTER BOX
Not displayed for HD SDI
signals
16:9, 15:9, 14:9, 13:9
Not displayed for HD SDI
signals
RET2
Return 2 signal
format, aspect,
and letterbox
aspect ratio
selection
Sequence of
format options:
1: HD SDI
2: SD SDI
3: VBS
When CAMERA FORMAT
is 1080/59.94i:
1080/59.94i
, 525/59.94i,
NTSC
When CAMERA FORMAT
is 720/59.94P: 720/59.94P,
525/59.94i, NTSC
When CAMERA FORMAT
is 1080/50i: 1080/50i,
625/50i, PAL
When CAMERA FORMAT
is 720/50P: 720/50P,
625/50i, PAL
SQUEEZE, EDGE CROP,
LETTER BOX
Not displayed for HD SDI
signals
16:9, 15:9, 14:9, 13:9
Not displayed for HD SDI
signals
RET3
Return 3 signal
format, aspect,
and letterbox
aspect ratio
selection
Sequence of
format options:
1: HD SDI
2: SD SDI
3: VBS
When CAMERA FORMAT
is 1080/59.94i:
1080/59.94i, 525/59.94i,
NTSC
When CAMERA FORMAT
is 720/59.94P: 720/59.94P,
525/59.94i, NTSC
When CAMERA FORMAT
is 1080/50i: 1080/50i,
625/50i, PAL
When CAMERA FORMAT
is 720/50P: 720/50P,
625/50i, PAL
SQUEEZE
, EDGE CROP,
LETTER BOX
Not displayed for HD SDI
signals
16:9
, 15:9, 14:9, 13:9
Not displayed for HD SDI
signals
Page name
Page No.
Item Settings
<RETURN
FORMAT>
S06
The RET1 to 4
signal outputs
support 16
combinations.
See “Return
Signal
Combinations”
on page 29.
RET4
Return 4 signal
format, aspect,
and letterbox
aspect ratio
selection
Sequence of
format options:
1: HD SDI
2: SD SDI
3: VBS
When CAMERA FORMAT
is 1080/59.94i:
1080/59.94i, 525/59.94i,
NTSC
When CAMERA FORMAT
is 720/59.94P: 720/59.94P,
525/59.94i, NTSC
When CAMERA FORMAT
is 1080/50i: 1080/50i,
625/50i, PAL
When CAMERA FORMAT
is 720/50P: 720/50P,
625/50i, PAL
SQUEEZE
, EDGE CROP,
LETTER BOX
Not displayed for HD SDI
signals
16:9
, 15:9, 14:9, 13:9
Not displayed for HD SDI
signals
SD RET ASPECT
SD return signal
aspect selection
AUTO, MANUAL
AUTO: Automatically
follows the SD output
aspect setting
MANUAL: Set manually,
independent of SD
output aspect setting
Page name
Page No.
Item Settings
