Setup Menu
CCU CONFIGURATION menu
Page name
Page No.
Item Settings
<COLOR BAR>
C01
HD BAR
HD output color bar settings
SEL BAR 16:9 (100%)
, BAR
16:9 (75%), SMPTE 16:9
(BLACK), SMPTE 16:9
(–I/Q), BAR 4:3 (100%),
BAR 4:3 (75%), SMPTE
4:3 (BLACK), SMPTE 4:3
(–I/Q), MF-ARIB (75%),
MF-ARIB (100%),
MF-ARIB (+I), MF-SMPTE
(–I,Q), MF-SMPTE
(75%,Q), MF-SMPTE
(100%,Q), MF-SMPTE
(+I,Q), HD-CUSTOM, SDI
CHECK FIELD, Y -RAMP,
Y/C-RAMP, HD-CUSTOM2
MF CB MODIFY
, EVEN
SLOPE WIDE
, NARROW
SD BAR
SD output color
bar setting
For NTSC: SMPTE
, EIA,
FULL, 95%, NTSC100%,
Y/C-RAMP, Y -RAMP,
DISABLE
For PAL: SMPTE
, EIA,
EBU, 95%, PAL100%,
Y/C-RAMP, Y -RAMP,
DISABLE
DISABLE: Down
conversion output of HD
color bar signal
BAR CHARA
Character
superimposed on
color bar signal
ON, OFF
GRAY ON, OFF
ON: Gray screen output
when camera power
supply is off
OFF: Color bar signal
output when camera
power supply is off
<BAR
CHARACTER>
C02
BAR CHARACTER Settings for strings 1 to 11
that are superimposed on
the color bar signal
<ALL CLEAR> ENTER to execute
Execute to clear all
character strings
<MONITOR 1>
C03
CHARACTER
WHITE LEVEL 0.0 to 107.0% 71.5
BLACK LEVEL 0.0 to 107.0%
PIX CHARACTER
WHITE LEVEL 75.0
to 107.0%
BLACK LEVEL 0.0
to 25.0%
<MONITOR 2>
C04
LEVEL GATE ---, 1&2, 1, 2, OFF
---: Displayed when
camera not connected,
video output not set to
CAMERA, or video
output is set to CAMERA
and GATE MARKER is
ON (read only)
Y LEVEL1
Level gate 1
minimum and
maximum
detection
levels and
zebra range
settings
0 to 108% 49
61
–99 to 99 –25
Y LEVEL2
Level gate 2
minimum and
maximum
detection
levels and
zebra range
settings
0 to 108% 74
108
–99 to 99 –25
GATE MARKER
Gate signal
display on/off and
signal level setting
---, ON, OFF
---: Displayed when
camera not connected
(read only)
–99 to 99 0
MODULATION
4:3 aspect ratio
mask function
on/off when
EDGE CROP is
ON, and mask
video level setting
---, ON, OFF
---: Displayed when
camera not connected
(read only)
–99 to 99 0
MARKER
Marker signal
on/off and
superimposed
signal selection
ON, OFF
4:3, 13:9, 14:9, EU VISTA,
VISTA, CINEMA, FOLLOW
DC
