Setup Menu
HXCU-100
4-140-418-12 (1)
NETWORK SETTINGS menu
Page name
Page No.
Item Settings
<TCP/IP
SETTING>
N01
IP ADDRESS 0.0.0.0
to 255.255.255.255
SUBNET MASK 0.0.0.0
to 255.255.255.255
DEFAULT
GATEWAY
0.0.0.0
to 255.255.255.255
SET ENTER to execute
A “SET OK?” message
is displayed. Press
ENTER again to confirm
the change.
<LAN
SETTINGS>
N02
AUTO
NEGOTIATION
ON
, OFF
AUTO MDI/MDIX ON
, OFF
CONNECTION
SPEED
10M, 100M
DUPLEX MODE HALF, FULL
MDI/MDIX MDI, MDIX
LINK CONDITION (DOWN), (UP)
(Read only)
SET ENTER to execute
A “SET OK?” message
is displayed. Press
ENTER again to confirm
the change.
<CNS
SETTINGS>
N03
CNS MODE
Network
connection mode
selection
LEGACY
, BRIDGE
LEGACY: External
controller connected
using CCA-5 cable only
BRIDGE: External
controller connected
using point-to-point LAN
cable
CCU NO Default: 0
1 to 96, A to Z
SET ENTER to execute
A “SET OK?” message
is displayed. Press
ENTER again to confirm
the change.
<NETWORK
RESET>
N04
ALL RESET ENTER to execute
A “NET SETTINGS
RESET OK?” message
is displayed. Press
ENTER again to reset
NETWORK SETTINGS
menu items to factory
default values.
