Setup Menu
<FRONT PANEL
1>
C15
Displayed only
when the
HKCU-FP1
CCU Control
Panel is fitted
VOLUME
HKCU-FP1
CCU Control
Panel
CUSTOM
knob
assignment
NOT ASSIGN
, HD
GAMMA, SD GAMMA, HD
DTL LEVEL, SD DTL
LEVEL, BLK GAMMA
NOT ASSIGN: Not
assigned (knob
deactivated)
HD GAMMA: HD
M-gamma setting
SD GAMMA: SD
M-gamma setting
HD DTL LEVEL: HD
detail level setting
SD DTL LEVEL: SD
detail level setting
BLK GAMMA: Black
gamma setting
VOLUME MODE
IRIS
IRIS knob
operating
mode
REL, ABS
REL: Relative value
mode
ABS: Absolute value
mode
M BLACK
MASTER
BLACK knob
operating
mode
REL
, ABS
REL: Relative value
mode
ABS: Absolute value
mode
R/B BLACK
BLACK/FLARE
knob function
and operating
mode
REL/BLACK, ABS/BLACK,
REL/FLARE, ABS/FLARE
REL/BLACK: BLACK
(relative value mode)
ABS/BLACK: BLACK
(absolute value mode)
REL/FLARE: FLARE
(relative value mode)
ABS/FLARE: FLARE
(absolute value mode)
R/B WHITE
WHITE knob
operating
mode
REL
, ABS
REL: Relative value
mode
ABS: Absolute value
mode
Page name
Page No.
Item Settings
<FRONT PANEL
2>
C16
Displayed only
when the
HKCU-FP1
CCU Control
Panel is fitted
VOLUME REL COEFF
IRIS
Relative
coefficient
when the IRIS
knob is set to
relative value
mode
1/1, 1/2
, 1/4
1/1: Variable range
roughly 100% of total
variation
1/2: Variable range
roughly 50% of total
variation
1/4: Variable range
roughly 25% of total
variation
M BLACK
Relative
coefficient
when the
MASTER
BLACK knob
is set to
relative value
mode
1/1, 1/2, 1/4
1/1: Variable range
roughly 100% of total
variation
1/2: Variable range
roughly 50% of total
variation
1/4: Variable range
roughly 25% of total
variation
R/B BLACK
Relative
coefficient
when the
BLACK/FLARE
knob is set to
relative value
mode
1/1, 1/2, 1/4, (FLARE)
1/1: Variable range
roughly 100% of total
variation
1/2: Variable range
roughly 50% of total
variation
1/4: Variable range
roughly 25% of total
variation
(FLARE): Displayed
when the
BLACK/FLARE knob is
assigned to the FLARE
function (read only)
R/B WHITE
Relative
coefficient
selection when
the WHITE
knob is set to
relative value
mode
1/1, 1/2, 1/4
1/1: Variable range
roughly 100% of total
variation
1/2: Variable range
roughly 50% of total
variation
1/4: Variable range
roughly 25% of total
variation
CUSTOM
Relative
coefficient
when the
CUSTOM
knob is set to
relative value
mode
1/1, 1/2
, 1/4
1/1: Variable range
roughly 100% of total
variation
1/2: Variable range
roughly 50% of total
variation
1/4: Variable range
roughly 25% of total
variation
SW BRIGHT
Front panel button
lights LED
brightness
NORMAL
, LOW
Page name
Page No.
Item Settings
