Menu Configuration and Basic Menu Operations
Menu 2ndary menu Submenu Control item Function
SD Adjusting SD Matrix Matrix 1 z R-G/G-B/B-R Set the matrix coefficients.
User Matrix Turns the user matrix ON/OFF.
Preset Matrix Turns the preset matrix ON/OFF.
Matrix Off Turns all the matrixes ON/OFF
Matrix 2 z R-B/G-R/B-G Set the matrix coefficients.
User Matrix Turns the user matrix ON/OFF.
Preset Matrix Turns the preset matrix ON/OFF.
Matrix Off Turns all matrixes ON/OFF.
SD Multi Matrix z Phase Select the multi matrix phase.
z Hue Adjust the multi marrâx hue.
z Sat Adjust the multi matrix saturation.
Multi Matrix Turns the multi matrix ON/OFF.
Matrix Off Turns all the matrixes ON/OFF
All Clear Clears all the multi matrix settings.
CCU Config Menu Cont
b)
Menu Disp On Displays the CCU Menu.
Enter Activates/deactivates “Enter.”
Cancel Activates/deactivates “Cancel.”
z Select Selects the menu item.
Super Motion Flicker Reduction
c)
Flicker Reduction Turns the flicker suppression of the HD Super-Motion
camera ON/OFF.
Field Rate
d)
[ x1, x3 ] Sets the field rate when using a Super-Motion camera.
Frame Interpolation
d)
[ OFF, A, B, C ] Sets the pattern to make the reference output picture in
3-times mode.
Flicker Reduction
d)
[ OFF, Normal, Strong ] Sets the flicker suppression in 3-times mode.
RCP Config RCP Adjusting Buzzer Volume z Call Adjusts the volume of the call buzzer.
z Touch Adjusts the volume of the response sound of the touch panel.
z Switch Adjusts the volume of the confirmation sound of self-
illuminating switches.
z Master Adjusts the total buzzer sound volume.
Call Buzzer Turns the call buzzer ON/OFF.
Touch Click Turns the response sound of the touch panel ON/OFF.
SW Click Turns the confirmation sound of switches ON/OFF.
All Off Turns all the buzzers ON/OFF.
LED Bright z Switch Adjust the brightness of the corresponding LEDs.
z Tally
z Other
z Master Adusts the master brightness of the LEDs.
Rotary Encoder BLACK/FLARE Black Selects the black balance adjustment.
Setting
Flare Selects the flare balance adjustment.
DETAIL Detail (HD) Selects the HD detail adjustment.
SD Detail Selects the SD detail adjustment.
b) This function becomes operable if enabled with g) (page 23(E)) or in Engineer mode only.
c) When connected to an HD system
d) When connected to an SD system
