Sony RDP-M5iP User Manual

9
4) Line up the batteries according to the + symbols inside the battery enclosure. See
Figure 7 below.
Figure 7 - Inside the Battery Enclosure
The System requires four Sony AAA/LR03 alkaline batteries or four Sony NH-AAA
rechargeable batteries. The batteries are not supplied with the System.
5) Insert the batteries into both battery enclosures.
6) Line up each battery cover over its battery enclosure.
7) Push in on each battery cover to snap it back into place.
The System is now configured to use a battery power source.
If you are using a battery power source with the System, do not expose the System to
excessive heat such as sunshine, fire, or the like for long periods of time–doing so could cause
the System to catch on fire or cause other damage to the System.
To be able to use a battery power source with the System, you have to ensure that the AC
power adapter is disconnected from the back of the System.
To preserve the life of the batteries, remove the batteries from the System when you are
using an electrical power source.
+ Symbol
+ Symbol

Sony RDP-M5iP Specifications

General

Driver diameter	50 mm
Frequency range	- Hz
RMS rated power	4 W
Audio output channels	2.0 channels
AUX in	Yes
Bluetooth	No
Headphone connectivity	-
Apple docking compatibility	iPhone, iPod
Battery type	AAA
Battery voltage	1.5 V
AC input voltage	100 - 240 V
Power source type	AC, Battery
Battery life (max)	10 h
Battery technology	Alkaline
Number of batteries supported	4
Product color	Black
Volume control	Digital
Speaker power	2 W
Dimensions (WxDxH)	226 x 184 x 165 mm

Weight and Dimensions

Weight	1100 g
