Sony RDP-M5iP User Manual

11
To attach your iPod
1) Looking at the front of the System, line up your iPod with the docking tray connector in
the middle of the docking tray–ensuring your iPod is at the same angle as the docking
tray connector. See Figure 8 below.
Figure 8 - Docking Tray Connector
2) Push your iPod down onto the docking tray connector.
3) Ensure that your iPod is securely fastened (e.g., that your iPod is pushed down all the
way and doesn’t move around).
Your iPod is now attached to the System.
A universal dock adapter does not come with the System, but you can contact the
manufacturer of your iPod to obtain one. If your iPod does not come with a universal dock
adapter, you can still attach your iPod to the System without using one (as shown in the
procedure above).
If you have a universal dock adapter that came with your iPod, follow the procedure
under “To attach your iPhone” to attach your iPod to the System.
Docking Tray
Connector
Docking
Tray

Sony RDP-M5iP Specifications

General

Driver diameter	50 mm
Frequency range	- Hz
RMS rated power	4 W
Audio output channels	2.0 channels
AUX in	Yes
Bluetooth	No
Headphone connectivity	-
Apple docking compatibility	iPhone, iPod
Battery type	AAA
Battery voltage	1.5 V
AC input voltage	100 - 240 V
Power source type	AC, Battery
Battery life (max)	10 h
Battery technology	Alkaline
Number of batteries supported	4
Product color	Black
Volume control	Digital
Speaker power	2 W
Dimensions (WxDxH)	226 x 184 x 165 mm

Weight and Dimensions

Weight	1100 g
