To use a battery power source
1) Looking at the back of the System, lay the System on its front so the bottom panel is
exposed.
You see a left battery cover and a right battery cover, which cover the two battery
enclosures. See Figure 6 below.
Figure 6 - Battery Covers and Outer Clips
2) Push in on the outer clips for each battery cover. See Figure 6 above.
3) Pull off the battery covers for each battery enclosure.
You see the inside of the battery enclosures.
Outer Clip
Outer Clip
