Sony RDP-M5iP User Manual

22
To power on the System
1) Point the remote commander at the remote sensor on the front of the System. See
Figure 14 below.
Figure 14 - Remote Sensor
2) On the remote commander, locate the power I / button. See Figure 15 below.
Figure 15 - Remote Commander Power Button
3) Press I / on the remote commander.
Remote
Sensor
Power I /
Button

Sony RDP-M5iP Specifications

General

Driver diameter	50 mm
Frequency range	- Hz
RMS rated power	4 W
Audio output channels	2.0 channels
AUX in	Yes
Bluetooth	No
Headphone connectivity	-
Apple docking compatibility	iPhone, iPod
Battery type	AAA
Battery voltage	1.5 V
AC input voltage	100 - 240 V
Power source type	AC, Battery
Battery life (max)	10 h
Battery technology	Alkaline
Number of batteries supported	4
Product color	Black
Volume control	Digital
Speaker power	2 W
Dimensions (WxDxH)	226 x 184 x 165 mm

Weight and Dimensions

Weight	1100 g
