— 8 —
5) Set the four flexible flat cables as shown in Fig. 11.
6) Set the flexible flat cable and the harness as shown in Fig. 12.
4
Connector
(CN110)
4
Connector
(CN201)
5
Harness
(6P: CN102)
3
Flexible flat cable
(FFC 25P: CN601)
4
Connector
(CN102)
5
Connector
(CN104)
6
Connector
(CN108)
8
Connector
(CN112)
3
Flexible flat cable
(FFC 11P: CN201)
7
Flexible flat cable
(FFC 15P: CN201)
2
Flexible flat cable
(FFC 9P: CN204)
1
Flexible flat cable
(FFC 26P: CN203)
7) Set is finished.
Fig. 11.
Fig. 12.
