Sony RMT-D187A - MS-203 Loading Motor Board Wiring

DVP-NS611HP/NS710H/NS710HP/NS717HP/NS718H/NS718HP/NS728H/NS728HP
LOADING MOTOR
MS-203
For Schematic Diagram
• Refer to page 4-9 for printed wiring board of MS-203 board.
MS-203 BOARD
LOADING MOTOR
-REF.NO.:1000 SERIES-
XX MARK:NO MOUNT
NO MARK:REC/PB MODE
1
A
B
C
D
2
765
43
MS-203 BOARD
CN001
S001
(CHUCK/TRAY DETECT)
C001
S001
1-861-327- 12 21
5
4
1
2
1
2
3
M001
(LOADING MOTOR)
+
-
MM
M001
5PCN001
1
2
3
4
5
JL001
JL002
JL003
JL004
JL005
TO MV-57 BOARD (2/5)
CN202
(SEE PAGE 4-15 TO 4-16)
LOADING
MOTOR
C001
XX
LDM+
LDM-
OCSW1
CKSW1
GND/CTL
S001
DETECT
CHUCK/TRAY
1
3
2
4-144-13
MS-203 (LOADING MOTOR) PRINTED WIRING BOARD
• : Uses unleaded solder.
There are a few cases that the part printed on
this diagram isn’t mounted in this model.
For printed wiring board
FB-224 Board
(USB)
(DVP-NS728H,NS728HP)
MV-62 Board (DVP-NS718H:EXCEPT CND,AUS/NS728H:AUS)
MV-60 Board (DVP-NS611HP/NS710H/NS710HP/NS717HP/
NS718H:CND,AUS/NS728HP/NS728H:AUS)
(SYSTEM, DRIVE, VIDEO, AUDIO, POWER)
IF-163 Board
(INTERFACE)
Switching Regulator Board
SRV2187UC (DVP-NS611HP/NS718H:CND/
NS717HP/NS710HP:MX2)
SRV2186WW (DVP-NS710H:PX3,NS718HP,
NS718H:EXCEPT CND,NS728H,NS728HP)
