Sony RMT-D187A - MV-60 Board Electrical Parts (Part 5); MV-62 Board Electrical Parts (Part 2)

8-9
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS611HP/NS 710H/N S710HP/NS717HP/NS718H/N S718HP /NS728 H/NS728HP
R1204 1-216-803-91 METAL CHIP 33 5% 1/10W
<CONDUCTOR>
RB105 1-234-959-21 RES, NETW ORK 75 (1005X4)
RB106 1-234-959-21 RES, NETW ORK 75 (1005X4)
RB107 1-234-944-21 RES, NETW ORK 47 (1005X4)
RB108 1-234-944-21 RES, NETW ORK 47 (1005X4)
<CRYSTAL>
X101 1-814-144-11 QUARTZ CRYSTAL UNIT
(DVP-NS718HP:SP,TH,KR,EA,KS,TW & AUS ONLY)
X101 1-813-924-21 QUARTZ CRYSTAL UNIT
(EXCEPT DVP-NS718HP:SP,TH,KR,EA,KS,TW & AUS ONLY)
A-1660-790-A SERVICE ASSY, MV-62 (DVP-NS728H:AEP,UK)
A-1660-892-A SERVI CE ASSY, MV-62 (DVP-NS718H:RUS)
A-1663-541-A SERVICE ASSY, MV-62 (DVP-NS728H:AEP,UK)
A-1704-162-A SERVI CE ASSY, MV-62 (DVP-NS728H:RUS)
******************************************
<CAPACITOR>
C101 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C102 1-125-777-81 CERAMIC CHIP 0.1UF 10.00% 10V
C103 1-100-909-11 CERAMIC CHIP 10UF 10% 6.3V
C105 1-128-994-21 ELECT CHIP 47UF 20% 10V
C106 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C107 1-112-717-91 CERAMIC CHIP 1UF 10% 6.3V
C109 1-125-777-81 CERAMIC CHIP 0.1UF 10.00% 10V
C111 1-128-994-21 ELECT CHIP 47UF 20% 10V
C112 1-128-994-21 ELECT CHIP 47UF 20% 10V
C113 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C115 1-125-777-81 CERAMIC CHIP 0.1UF 10.00% 10V
C116 1-125-777-81 CERAMIC CHIP 0.1UF 10.00% 10V
C118 1-100-909-11 CERAMIC CHIP 10UF 10% 6.3V
C119 1-100-909-11 CERAMIC CHIP 10UF 10% 6.3V
C120 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C121 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C122 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C123 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C124 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C125 1-125-777-81 CERAMIC CHIP 0.1UF 10.00% 10V
C126 1-125-777-81 CERAMIC CHIP 0.1UF 10.00% 10V
C129 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C134 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C140 1-112-717-91 CERAMIC CHIP 1UF 10% 6.3V
C1
41 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C142 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C143 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C144 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C145 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C147 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C148 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V
C150 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C151 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C152 1-162-918-91 CERAMIC CHIP 18PF 5.00% 50V
(DVP-NS728H:AEP,UK & RUS ONLY)
C152 1-162-917-91 CERAMIC CHIP 15PF 5.00% 50V
(DVP-NS718H:AEP,UK & RUS ONLY)
C153 1-162-917-91 CERAMIC CHIP 15PF 5.00% 50V
C156 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C157 1-165-884-91 CERAMIC CHIP 2.2UF 10% 6.3V
C159 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C160 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C162 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C163 1-164-938-81 CERAMIC CHIP 0.0015UF 10.00% 50V
C164 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C165 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C166 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C167 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C1
69 1-125-777-81 CERAMIC CHIP 0. 1UF 10.00% 10V
C177 1-128-994-21 ELECT CHIP 47UF 20% 10V
C179 1-125-777-81 CERAMIC CHIP 0. 1UF 10.00% 10V
C180 1-125-777-81 CERAMIC CHIP 0. 1UF 10.00% 10V
C181 1-125-777-81 CERAMIC CHIP 0. 1UF 10.00% 10V
C182 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C183 1-114-411-21 CERAMIC CHIP 0. 33UF 10% 6.3V
C184 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C185 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C186 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C187 1-126-208-21 ELECT CHIP 47UF 20.00% 4V
C189 1-125-777-81 CERAMIC CHIP 0. 1UF 10.00% 10V
C190 1-128-994-21 ELECT CHIP 47UF 20% 10V
C191 1-125-777-81 CERAMIC CHIP 0. 1UF 10.00% 10V
C192 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C193 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C195 1-127-715-91 CERAMIC CHIP 0. 22UF 10% 16V
C197 1-125-777-81 CERAMIC CHIP 0. 1UF 10.00% 10V
C198 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C199 1-162-968-91 CERAMIC CHIP 0.0047UF 10.00% 50V
C203 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C205 1-164-882-81 CERAMIC CHIP 220PF 5.00% 16V
C206 1-164-882-81 CERAMIC CHIP 220PF 5.00% 16V
C208 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C2
09 1-127-772-81 CERAMIC CHIP 0. 033UF 10% 10V
C210 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C211 1-127-772-81 CERAMIC CHIP 0. 033UF 10% 10V
C212 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C213 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C214 1-164-937-81 CERAMIC CHIP 0. 001UF 10.00% 50V
C215 1-162-970-91 CERAMIC CHIP 0. 01UF 10.00% 25V
C217 1-128-994-21 ELECT CHIP 47UF 20% 10V
C218 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C219 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C220 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C221 1-107-826-91 CERAMIC CHIP 0. 1UF 10.00% 16V
C222 1-107-826-91 CERAMIC CHIP 0. 1UF 10.00% 16V
C224 1-100-567-81 CERAMIC CHIP 0. 01UF 10% 25V
C225 1-164-937-81 CERAMIC CHIP 0. 001UF 10.00% 50V
MV-62MV-60
The components identied by mark
contain condential information.
Strictly follow the instructions
whenever the components are repaired
and/or replaced.
