8-10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS611HP/NS710H/NS710HP/NS717HP/NS718H/NS718HP/NS728H/NS728HP
C226 1-164-937-81 CERAMIC CHIP 0.001UF 10.00% 50V
C233 1-164-941-81 CERAMIC CHIP 0.0047UF 10.00% 16V
C301 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C318 1-164-866-81 CERAMIC CHIP 47PF 5.00% 50V
C319 1-164-874-81 CERAMIC CHIP 100PF 5.00% 50V
C320 1-164-874-81 CERAMIC CHIP 100PF 5.00% 50V
C321 1-164-874-81 CERAMIC CHIP 100PF 5.00% 50V
C322 1-164-866-81 CERAMIC CHIP 47PF 5.00% 50V
C327 1-126-379-21 ELECT CHIP 22UF 20.00% 16V
C328 1-128-994-21 ELECT CHIP 47UF 20% 10V
C329 1-128-994-21 ELECT CHIP 47UF 20% 10V
C331 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C332 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C333 1-128-994-21 ELECT CHIP 47UF 20% 10V
C334 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C335 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C401 1-164-937-81 CERAMIC CHIP 0.001UF 10.00% 50V
C402 1-164-937-81 CERAMIC CHIP 0.001UF 10.00% 50V
C405 1-164-876-81 CERAMIC CHIP 120PF 5.00% 50V
C406 1-164-876-81 CERAMIC CHIP 120PF 5.00% 50V
C408 1-100-567-81 CERAMIC CHIP 0.01UF 10% 25V
C413 1-117-681-21 ELECT CHIP 100UF 20.00% 16V
C415 1-164-882-81 CERAMIC CHIP 220PF 5.00% 16V
C416 1-164-882-81 CERAMIC CHIP 220PF 5.00% 16V
C423 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C424 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C428 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C442 1-165-908-91 CERAMIC CHIP 1UF 10% 10V
C443 1-124-779-21 ELECT CHIP 10UF 20.00% 16V
C444 1-126-204-21 ELECT CHIP 47UF 20.00% 16V
C447 1-100-909-11 CERAMIC CHIP 10UF 10% 6.3V
C448 1-100-909-11 CERAMIC CHIP 10UF 10% 6.3V
C501 1-128-994-21 ELECT CHIP 47UF 20% 10V
C502 1-128-994-21 ELECT CHIP 47UF 20% 10V
C504 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C505 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C506 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C507 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V
C1102 1-125-777-81 CERAMIC CHIP 0.1UF 10.00% 10V
<CONNECTOR>
CN101 1-815-763-32 CONNECTOR, FFC/FPC 24P
CN102 1-821-398-11 HDMI CONNECTOR
CN105 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN106 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN201 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN202 1-794-362-51 CONNECTOR, FFC/FPC 5P
* CN501 1-564-009-11 PIN, CONNECTOR 10P
<DIODE>
D303 6-501-675-01 DIODE HZM6.8ZMWATL-E
D304 6-501-675-01 DIODE HZM6.8ZMWATL-E
D305 6-501-675-01 DIODE HZM6.8ZMWATL-E
D306 6-501-675-01 DIODE HZM6.8ZMWATL-E
D309 8-719-069-56 DI UDZSUSTE-176.2B
D310 8-719-083-63 DI UDZSUSTE-1713B
D311 6-501-675-01 DIODE HZM6.8ZMWATL-E
D312 6-501-675-01 DIODE HZM6.8ZMWATL-E
D313 6-501-675-01 DIODE HZM6.8ZMWATL-E
D314 6-501-675-01 DIODE HZM6.8ZMWATL-E
D315 6-501-817-01 DIODE MA2J1110GLS0
D401 6-501-817-01 DIODE MA2J1110GLS0
D403 6-501-726-01 DIODE MAZ8047GMLS0
<FERRITE>
FB106 1-469-324-21 FERRITE 0UH
FB108 1-469-324-21 FERRITE 0UH
FB111 1-469-670-21 FERRITE 0UH
FB112 1-469-670-21 FERRITE 0UH
FB115 1-400-382-21 FERRITE 0UH
FB116 1-414-226-21 FERRITE 0UH
FB123 1-400-382-21 FERRITE 0UH
FB124 1-469-670-21 FERRITE 0UH
FB501 1-469-324-21 FERRITE 0UH
FB502 1-469-324-21 FERRITE 0UH
FB504 1-469-324-21 FERRITE 0UH
<IC>
IC102 6-712-212-01 IC MX25L3205DM2I-12G
IC103 SEE NOTE ABOVE
IC105 6-702-302-01 IC TK11133CSCL-G
IC106 6-706-487-01 IC TC7SH08FU(T5RSOYJF)
IC107 6-702-302-01 IC TK11133CSCL-G
IC108 6-703-224-01 IC S-80828CNNB-B8NT2G
IC109 6-705-337-01 IC TK11150CSCL-G
IC110 6-707-739-01 IC MM1661JTRE
IC112 6-702-302-01 IC TK11133CSCL-G
IC201 6-704-524-01 IC FAN8036L
IC303 8-759-667-17 IC L79M05TLL-SONY-TL-E
IC305 6-706-453-01 IC NJM2587V(TE2)
IC407 8-759-278-58 IC NJM4558V-TE2
<JACK>
J401 1-784-431-11 JACK, PIN 1P
<INDUCTOR>
L301 1-412-979-41 INDUCTOR 1UH
LF101 1-457-374-21 INDUCTOR 0UH
LF102 1-457-374-21 INDUCTOR 0UH
LF103 1-457-374-21 INDUCTOR 0UH
LF104 1-457-374-21 INDUCTOR 0UH
MV-62
The components identified by mark
or dotted line with mark are critical
for safety.
Replace only with part number
specified.
Notes:
MV-62 Board must be replaced if
IC103 (EEPROM) is damaged or not functioning.
The old MV-62 Board must be completely disposed.
