Sony RMT-D187A - MV-62 Board Electrical Parts (Part 4)

8-11
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DVP-NS611HP/NS710H/NS710HP/NS717HP/NS718H/NS718HP/NS728H/NS728HP
<FUSE>
* PS501 1-576-892-11 FUSE 1A 0V
* PS502 1-576-892-11 FUSE 1A 0V
<TRANSISTOR>
Q101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-424-63 TRANSISTOR UN2212-TX
Q104 6-550-008-01 TRANSISTOR UM6K1N-TN
Q105 8-729-028-27 TRANSISTOR 2SK2009(TE85L)
Q375 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q376 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q377 8-729-038-17 TRANSISTOR RT1P441C-TP-1
Q401 8-729-038-12 TRANSISTOR RT1P141C-TP-1
Q402 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q403 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q405 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
* Q407 6-551-959-01 TRANSISTOR IMX25T110
Q411 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q417 8-729-038-22 TRANSISTOR RT1N140C-TP-1
Q501 6-551-458-01 TRANSISTOR KTD1624-B
Q502 8-729-038-13 TRANSISTOR RT1P144C-TP-1
<RESISTOR>
R102 1-216-864-91 SHORT CHIP 0
R103 1-208-659-81 METAL CHIP 100 0.5% 1/16W
R104 1-208-896-81 METAL CHIP 2.4K 0.5% 1/16W
R105 1-216-864-91 SHORT CHIP 0
R106 1-216-864-91 SHORT CHIP 0
R107 1-218-965-81 METAL CHIP 10K 5% 1/16W
R108 1-216-857-91 METAL CHIP 1M 5% 1/10W
R109 1-218-990-81 SHORT CHIP 0
R110 1-218-973-81 METAL CHIP 47K 5% 1/16W
R111 1-216-809-91 METAL CHIP 100 5% 1/10W
R112 1-211-977-91 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-91 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-91 METAL CHIP 100K 5% 1/10W
R115 1-211-977-91 METAL CHIP 22 0.5% 1/10W
R116 1-218-953-81 METAL CHIP 1K 5% 1/16W
R117 1-218-973-81 METAL CHIP 47K 5% 1/16W
R118 1-216-801-91 METAL CHIP 22 5% 1/10W
R120 1-216-801-91 METAL CHIP 22 5% 1/10W
R121 1-216-801-91 METAL CHIP 22 5% 1/10W
R122 1-216-864-91 SHORT CHIP 0
R123 1-218-990-81 SHORT CHIP 0
R124 1-218-973-81 METAL CHIP 47K 5% 1/16W
R125 1-218-990-81 SHORT CHIP 0
R126 1-218-965-81 METAL CHIP 10K 5% 1/16W
R127 1-218-961-81 METAL CHIP 4.7K 5% 1/16W
R128 1-218-961-81 METAL CHIP 4.7K 5% 1/16W
R130 1-218-965-81 METAL CHIP 10K 5% 1/16W
R131 1-216-864-91 SHORT CHIP 0
R132 1-216-864-91 SHORT CHIP 0
R133 1-218-973-81 METAL CHIP 47K 5% 1/16W
R136 1-216-864-91 SHORT CHIP 0
R137 1-218-990-81 SHORT CHIP 0
R138 1-218-961-81 METAL CHIP 4.7K 5% 1/16W
R139 1-216-864-91 SHORT CHIP 0
R140 1-216-824-91 METAL CHIP 1.8K 5% 1/10W
R142 1-216-845-91 METAL CHIP 100K 5% 1/10W
R144 1-218-990-81 SHORT CHIP 0
R145 1-218-990-81 SHORT CHIP 0
R146 1-218-990-81 SHORT CHIP 0
R147 1-218-990-81 SHORT CHIP 0
R148 1-218-990-81 SHORT CHIP 0
R149 1-216-824-91 METAL CHIP 1.8K 5% 1/10W
R150 1-216-864-91 SHORT CHIP 0
R151 1-218-965-81 METAL CHIP 10K 5% 1/16W
R151 1-218-965-81 METAL CHIP 10K 5% 1/16W
R156 1-218-941-81 METAL CHIP 100 5% 1/16W
R157 1-216-864-91 SHORT CHIP 0
R160 1-218-990-81 SHORT CHIP 0
R162 1-218-990-81 SHORT CHIP 0
R163 1-218-990-81 SHORT CHIP 0
R165 1-218-959-81 METAL CHIP 3.3K 5% 1/16W
R166 1-216-864-91 SHORT CHIP 0
R168 1-216-864-91 SHORT CHIP 0
R174 1-216-864-91 SHORT CHIP 0
R178 1-216-864-91 SHORT CHIP 0
R181 1-218-990-81 SHORT CHIP 0
R183 1-218-990-81 SHORT CHIP 0
R185 1-218-965-81 METAL CHIP 10K 5% 1/16W
R189 1-211-983-91 METAL CHIP 39 0.5% 1/10W
R190 1-211-990-91 METAL CHIP 75 0.5% 1/10W
R191 1-218-953-81 METAL CHIP 1K 5% 1/16W
R192 1-211-990-91 METAL CHIP 75 0.5% 1/10W
R193 1-218-953-81 METAL CHIP 1K 5% 1/16W
R194 1-218-965-81 METAL CHIP 10K 5% 1/16W
R195 1-211-983-91 METAL CHIP 39 0.5% 1/10W
R196 1-216-864-91 SHORT CHIP 0
R199 1-216-864-91 SHORT CHIP 0
R204 1-218-954-81 METAL CHIP 1.2K 5% 1/16W
R205 1-218-965-81 METAL CHIP 10K 5% 1/16W
R206 1-218-965-81 METAL CHIP 10K 5% 1/16W
R207 1-218-958-81 METAL CHIP 2.7K 5% 1/16W
R208 1-218-971-81 METAL CHIP 33K 5% 1/16W
R209 1-218-971-81 METAL CHIP 33K 5% 1/16W
R210 1-218-973-81 METAL CHIP 47K 5% 1/16W
R212 1-218-965-81 METAL CHIP 10K 5% 1/16W
R213 1-218-963-81 METAL CHIP 6.8K 5% 1/16W
R214 1-218-967-81 METAL CHIP 15K 5% 1/16W
R215 1-218-966-81 METAL CHIP 12K 5% 1/16W
R216 1-218-966-81 METAL CHIP 12K 5% 1/16W
R219 1-218-970-81 METAL CHIP 27K 5% 1/16W
R220 1-218-953-81 METAL CHIP 1K 5% 1/16W
R221 1-208-929-81 METAL CHIP 56K 0.5% 1/16W
R222 1-218-971-81 METAL CHIP 33K 5% 1/16W
R223 1-208-935-81 METAL CHIP 100K 0.5% 1/16W
R224 1-218-965-81 METAL CHIP 10K 5% 1/16W
R225 1-208-935-81 METAL CHIP 100K 0.5% 1/16W
R226 1-208-929-81 METAL CHIP 56K 0.5% 1/16W
R230 1-208-933-81 METAL CHIP 82K 0.5% 1/16W
R231 1-208-915-81 METAL CHIP 15K 0.5% 1/16W
R232 1-208-917-81 METAL CHIP 18K 0.5% 1/16W
R233 1-208-923-81 METAL CHIP 33K 0.5% 1/16W
R234 1-218-965-81 METAL CHIP 10K 5% 1/16W
MV-62
