1-34
138
Specifications
System
Laser: Semiconductor laser
Channel coverage:
PAL/SECAM (B/G, D/K, I, L)
VHF: E2 to E12, R1 to R12, F2 to F10,
Italian A to H, Ireland A to J, South
Africa 4 to 11, 13
UHF: E21 to E69, R21 to R69, B21 to
B69, F21 to F69
CATV: S01 to S05, S1 to S20, France
B to Q
HYPER: S21 to S41
The above channel coverage merely ensures
the channel reception within these ranges. It
does not guarantee the ability to receive
signals in all circumstances. For details, see
“Receivable channels” (page 112).
Video reception: Frequency synthesizer
system
Audio reception: Split carrier system
Aerial out: 75-ohm asymmetrical aerial
socket
Timer: Clock: Quartz locked/Timer
indication: 24-hour cycle (digital)/
Power back-up duration: 1 hour
Video recording format: MPEG-2,
MPEG-1
Audio recording format/applicable
bit rate: Dolby Digital 2 ch
256 kbps/128 kbps (in EP, SLP, and
SEP mode), PCM
Inputs and outputs
LINE 2 OUT
(AUDIO): Phono jack/2 Vrms/10 kilohms
(VIDEO): Phono jack/1.0 Vp-p
(S VIDEO): 4-pin mini DIN/Y: 1.0 Vp-p,
C: 0.3 Vp-p (PAL)
LINE 2 IN
(AUDIO): Phono jack/2 Vrms/more than
22 kilohms
(VIDEO): Phono jack/1.0 Vp-p
(S VIDEO): 4-pin mini DIN/Y: 1.0 Vp-p,
C: 0.3 Vp-p (PAL)
LINE 3 – TV: 21-pin
CVBS OUT
S-Video/RGB OUT (upstream)
LINE 1/DECODER: 21-pin
CVBS IN/OUT
S-Video/RGB IN
Decoder
DV IN: 4-pin/i.LINK S100
DIGITAL OUT (COAXIAL): Phono jack/
0.5 Vp-p/75 ohms
COMPONENT VIDEO OUT
(Y, P
B/CB, PR/CR):
Phono jack/Y: 1.0 Vp-p,
P
B/CB: 0.7 Vp-p, PR/CR: 0.7 Vp-p
G-LINK: mini jack
HDMI OUT: HDMI 19-pin-Standard
Connector
USB:
USB jack Type A (For connecting
digital still camera, Memory card
reader and USB memory)
USB jack Type B (For connecting
PictBridge-compatible printers)
General
Power requirements: 220-240 V AC,
50/60 Hz
Power consumption: 44 W
Dimensions (approx.):
430 × 66.5 × 286 mm (width/height/
depth) incl. projecting parts
Hard disk drive capacity:
RDR-HX750: 160 GB
RDR-HX950: 250 GB
Mass (approx.): 4.4 kg
Operating temperature: 5ºC to 35ºC
Operating humidity: 25% to 80%
Supplied accessories:
Mains lead (1)
Aerial cable (1)
Remote commander (remote) (1)
Set top box controller (1)
R6 (size AA) batteries (2)
Specifications and design are subject to
change without notice.
139
Additional Information
Notes on MP3 Audio
Tracks, JPEG Image
Files, and DivX Video
Files
MP3 is an audio compression technology that
satisfies certain ISO/MPEG regulations.
JPEG is an image compression technology.
You can play MP3 (MPEG1 Audio Layer 3)
format audio tracks and JPEG image files on
the HDD or DATA CDs (CD-ROMs/CD-Rs/
CD-RWs) or JPEG image files on the HDD
or DATA DVDs (DVD-ROMs/DVD+RWs/
DVD+Rs/DVD-RWs/DVD-Rs).
DivX
®
is a video file compression
technology, developed by DivX, Inc. This
product is an official DivX
®
Certified
product. You can play DATA CDs (CD-
ROMs/CD-Rs/CD-RWs) and DATA DVDs
(DVD-ROMs/DVD+RWs/DVD+Rs/DVD-
RWs/DVD-Rs) that contain DivX video files.
DATA DVDs must be recorded according to
ISO9660 Level 1, Level 2, Romeo, Joliet, or
UDF (Universal Disk Format) 1.02, 1.50,
2.00*, or 2.01 format for the recorder to
recognise the MP3 tracks, JPEG image files,
and DivX video files.
DATA CDs must be recorded according to
ISO9660 Level 1, Level 2, Romeo, or Joliet
format for the recorder to recognise the MP3
tracks, JPEG image files, and DivX video
files.
You can also play discs recorded in
MultiSession/Border.
See the instructions supplied with the disc
drives and the recording software (not
supplied) for details on the recording format.
* Not available for MP3 audio tracks.
Note on MultiSession/Border discs
If audio tracks and images in Music CD
format or Video CD format are recorded in
the first session/border, only the first session/
border will be played back.
The recorder can play the following tracks
and files:
– MP3 audio tracks with the extension
“.mp3.”
– JPEG image files with the extension “.jpeg”
or “.jpg.”
– Baseline JPEG image files that conform to
the Exif 2.2* image files format, and
Y:C
B
:C
R
is 4:4:4, 4:2:2, or 4:2:0.
– DivX video files with the extension “.avi”
or “.divx.”
* “Exchangeable Image File Format”: The file
format used by digital still cameras.
z Hint
Since a disc with many trees takes longer to start
playback, it is recommended that you create albums
with no more than two trees.
b
Notes
• The recorder will play any data with the extension
“.mp3,” “.jpeg,” “.jpg,” “.avi,” or “.divx” even if
they are not in MP3, JPEG, or DivX format.
Playing these data may generate a loud noise
which could damage your speaker system.
• Depending on the disc, normal playback may not
be possible. For example, the picture may be
unclear, playback may not appear smooth, the
sound may skip, and so on.
• Depending on the disc, playback may take some
time to start.
• Some files cannot be played.
• For MP3 audio tracks and DivX video files, the
recorder can play up to 99 albums each on a
DATA CD or DATA DVD. Up to 99 tracks and
files under an album can be played.
• For JPEG image files, the recorder can load up to
99 albums and/or up to 999 files under an album
on a DATA CD/DATA DVD or the connected
USB device at a time. To view unloaded albums,
reload them.
• Proceeding to the next or another album may take
some time.
• The image size that can be displayed is limited.
The following image sizes can be displayed:
width 160–5,120 pixels by height 120–3,840
pixels.
• This recorder supports MP3 audio tracks
recorded with a sampling frequency of 32 kHz,
44.1 kHz, and 48 kHz.
• No more than a 1 GB MP3 audio track can be
played.
About MP3 audio tracks, JPEG
image files, and DivX video
files
MP3 audio tracks, JPEG image
files, or DivX video files that
the recorder can play
,continued
140
• The recorder does not conform to audio tracks in
mp3PRO format.
• The recorder cannot play a DivX video file of a
size larger than 720 (width) × 576 (height)/4 GB.
• The recorder may not play a DivX video file
when the file has been combined from two or
more DivX video files.
Notes on copying JPEG image files/MP3
audio tracks
• You cannot copy JPEG image files/MP3 audio
tracks to the HDD if:
– The total number of JPEG image albums on the
HDD exceeds 999.
– The total number of JPEG image files/MP3
audio tracks under an album exceeds 999.
– The MP3 audio tracks are 1 GB or larger.
• Note that the size of JPEG image files copied to
the HDD may be automatically increased to fit the
TV screen.
• You cannot copy JPEG image files onto a DATA
DVD finalised on other recorders or devices.
• If a warning message indicating that the HDD is
full appears, erase several albums or files to make
space. For details on erasing tracks or files, see
page 97 or 105.
About i.LINK
The
DV IN
jack on this recorder is i.LINK-
compliant for digital video cameras. This
section describes the i.LINK standard and its
features.
What is i.LINK?
i.LINK is a digital serial interface for
handling digital video, digital audio and other
data in two directions between equipment
having the i.LINK jack, and for controlling
other equipment.
i.LINK-compatible equipment can be
connected by a single i.LINK cable. Possible
applications are operations and data
transactions with various digital AV
equipment. When two or more i.LINK-
compatible equipment are connected to this
recorder in a daisy chain, operations and data
transactions are possible with not only the
equipment that this recorder is connected to
but also with other devices via the directly
connected equipment.
Note, however, that the method of operation
sometimes varies according to the
characteristics and specifications of the
equipment to be connected, and that
operations and data transactions are
sometimes not possible on some connected
equipment.
b
Note
Normally, only one piece of equipment can be
connected to this recorder by the i.LINK cable (DV
connecting cable). When connecting this recorder
to i.LINK-compatible equipment having two or
more i.LINK jacks (DV jacks), see the instruction
manual of the equipment to be connected.
i.LINK is a more familiar term for IEEE 1394
data transport bus proposed by SONY, and is
a trademark approved by many corporations.
IEEE 1394 is an international standard
standardized by the Institute of Electrical and
Electronics Engineers.
About the name “i.LINK”
141
Additional Information
i.LINK’s maximum baud rate varies
according to the equipment. Three maximum
baud rates are defined:
S100 (approx. 100 Mbps*)
S200 (approx. 200 Mbps)
S400 (approx. 400 Mbps)
The baud rate is listed under “Specifications”
in the instruction manual of each equipment.
It is also indicated near the i.LINK jack on
some equipment.
The maximum baud rate of equipment on
which it is not indicated such as this unit is
“S100.”
When units are connected to equipment
having a different maximum baud rate, the
baud rate sometimes differs from the
indicated baud rate.
* What is Mbps?
Mbps stands for megabits per second, or the
amount of data that can be sent or received in one
second. For example, a baud rate of 100 Mbps
means that 100 megabits of data can be sent in
one second.
For details on how to dub when this recorder
is connected to other video equipment having
DV jacks, see page 84.
The DV jack on this recorder can only input
DVC-SD signals. It cannot output signals.
The DV jack will not accept MICRO MV
signals from equipment such as a MICRO
MV digital video camera with an i.LINK
jack.
For further precautions, see the notes on
page 84.
For details on precautions when connecting
this recorder, also see the instruction manuals
for the equipment to be connected.
Use the Sony i.LINK 4-pin-to-4-pin cable.
i.LINK and are trademarks.
i.LINK baud rate
i.LINK functions on this
recorder
Required i.LINK cable
