8-14
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R614 1-216-864-11 SHORT CHIP 0 (HX780: CND, E)
R615 1-216-864-11 SHORT CHIP 0
(HX780: TH, SP/HX980: TH, SP)
R616 1-216-864-11 SHORT CHIP 0
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R619 1-216-833-11 METAL CHIP 10K 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R620 1-216-864-11 SHORT CHIP 0
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R621 1-216-809-11 METAL CHIP 100 5% 1/10W
(HX780: AUS, CND, E)
R621 1-414-760-21 INDUCTOR, FERRITE BEAD
(HX780: TH, SP/HX980: TH, SP)
R622 1-216-809-11 METAL CHIP 100 5% 1/10W
(HX780: AUS, CND, E)
R622 1-414-760-21 INDUCTOR, FERRITE BEAD
(HX780: TH, SP/HX980: TH, SP)
R623 1-216-821-11 METAL CHIP 1K 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R624 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R625 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R626 1-216-821-11 METAL CHIP 1K 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R627 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R628 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R630 1-216-815-11 METAL CHIP 330 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R631 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R632 1-216-801-11 METAL CHIP 22 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R633 1-216-809-11 METAL CHIP 100 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R634 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
R635 1-216-864-11 SHORT CHIP 0
R636 1-216-864-11 SHORT CHIP 0 (HX780: CND, E)
R637 1-216-864-11 SHORT CHIP 0 (HX780: CND, E)
R701 1-216-849-11 METAL CHIP 220K 5% 1/10W
< TUNER >
U601 1-693-741-11 TUNER (TMFE2-407A)
(HX780: AUS/HX980: AUS)
U601 1-693-742-11 TUNER (TMQH4-706A) (HX780: CND, E)
U601 1-693-744-11 TUNER (TMQZ2-453A)
(HX780: TH, SP/HX980: TH, SP)
< VIBRATOR >
* X101 1-813-965-31 VIBRATOR, CRYSTAL (15MHz)
X102 1-795-950-11 VIBRATOR, CRYSTAL (32.768kHz)
* X601 1-813-713-21 VIBRATOR, CRYSTAL (18.432MHZ)
(HX780: AUS, TH, SP/HX980: AUS, TH, SP)
************************************************************
A-1520-886-A FL-184 (AG) BOARD, COMPLETE
(HX680/HX780: AEP, UK, RUS/HX785/HX980: AEP, RUS/HX1080)
A-1543-613-A FL-184 (AS) BOARD, COMPLETE
(HX780: AUS, SP, TH, CND, E/HX980: AUS, TH, SP)
********************
< CAPACITOR >
C101 1-115-156-11 CERAMIC CHIP 1uF 10V
C102 1-115-156-11 CERAMIC CHIP 1uF 10V
C107 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C111 1-117-681-11 ELECT CHIP 100uF 20% 16V
< CONNECTOR >
CN104 1-819-866-11 CONNECTOR, USB (A) (USB A TYPE)
CN105 1-817-693-11 CONNECTOR, USB (B) (USB B TYPE)
CN106 1-815-381-11 CONNECTOR, FPC/FFC 5P
< CHOKE COIL >
FL101 1-456-390-21 COMMOM MODE CHOKE COIL
FL102 1-456-390-21 COMMOM MODE CHOKE COIL
< IC >
IC101 6-600-392-01 IC GP1UM27XK0SF
< COIL >
L102 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
L103 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
L104 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
L105 1-400-180-21 INDUCTOR, EMI FERRITE (1608)
< RESISTOR >
R104 1-216-803-11 METAL CHIP 33 5% 1/10W
R105 1-216-803-11 METAL CHIP 33 5% 1/10W
R108 1-216-803-11 METAL CHIP 33 5% 1/10W
R109 1-216-803-11 METAL CHIP 33 5% 1/10W
R112 1-216-864-11 SHORT CHIP 0
R113 1-216-864-11 SHORT CHIP 0
< SWITCH >
S101 1-786-726-11 SWITCH, TACTILE (POWER)
S102 1-771-410-21 SWITCH, TACTILE (ONE TOUCH DUB)
< VARISTOR >
VDR102 1-802-071-21 VARISTOR, CHIP
VDR104 1-802-071-21 VARISTOR, CHIP
************************************************************
FL-184AV-134
