Sony RMT-D249P - Disassembly Procedure Overview; Component Disassembly Flowchart

2-1
RDR-HX680/HX780/HX785/HX980/HX1080
SECTION 2
DISASSEMBLY
NOTE: The following flow chart shows the disassembly procedure.
Set
Upper case
(Page 2-1)
Tray cover assembly
(Page 2-2)
HDD unit
(Page 2-7)
Front panel block
(Page 2-3)
FR-291 board,
FL-184 board
(Page 2-4)
DVD unit
(Page 2-5)
Switching regulator
(Page 2-9)
AV-133/134 board
(Page 2-8)
DC fan
(Page 2-6)
