Sony RMT-D249P - DC Fan; Hard Unit

2-5
2-6. DC FAN
1 Two screws (+BV3)
2 Screw (+BV3)
5 RH-059 or RH-060 harness
(7pin) (power)
4 PH-080 harness
(4pin) (data)
6 Two screws
6-32UNCX4 (SG)
7 Two screws
6-32UNCX4 (SG)
8 HDD unit
3 Screw (+BV3)
and wire clamp
3 Two screws
(+BV3)
4 DC fan
2 Non-halogene tape
Air flow
1 Fan harness
(2p) (CN201)
AV-133/134 board
