1-8
1-4-9. Laser Caution Label
A new Holder Assy, Chuck part do not have Laser Caution Label.
Need to reuse the original Laser Caution label and paste it on top of new Holder Assy, Chuck .
Limit Sample
Following peel off position are acceptable
Loading Assy
Laser Caution Label
Holder Assy, Chuck (CI-J)
Tape
Dressing, FFC
FFC, OPT
FFC, SPD
FFC, LDG
1-4-8. MD (Mechanical Deck) Assy for Service
MD Assy service parts consists of 2 parts.
① Holder Assy, Chuck (A-2189-191-B)
② Loading Assy (A-2143-751-A)
Above service part ① & ② can be used for both UBP-X700/UX70.
To Next Page
