Sony RMT-VB201D - Disassembly; Disassembly Flow; Case Upper

2-1
1
SECTION 2
DISASSEMBLY
This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
2-2. CASE UPPER
SET
2-2 CASE UPPER
2-3 PANEL FRONT
& FR PWB
2-4 WIFI & MB
PWB
2-5 BD DRIVE
Three Screw +BTP 3X8 TYPE2 N-S
(tightening torque = 6.5 to 7.5kgf*cm)
1.
Case, Upper
2.
