Sony RMT-VB201D - Drive Test and OP Data Write

5-10
Outline：
Activate Drive test
(Window 1) Select Drive test category
Operation
：
[LEFT] [RIGHT]
[DOWN][ENT]
[RET]
Select Category
Activate the s elected Category.
Return to Service To p Menu.
[1] Drive OP data Write
[2] Servo Parameter Check Menu (Not Used)
[3] Servo Signal Check Menu (Not Used)
[4] S-Curve Check Menu (Not Used)
[5] Readability Check Menu (Not Used)
[6] OP Po s ition Check Menu (Not Used)
[7] OP Check Menu
[8] Lo ad Eject Aging (Not Used)
[9] Spindle Co ntrol Check Menu (Not Used)
[10] FA Tes t Mo de (Not Used)
(Window 2) To start OP data Write
Operation :
[ENT] Start
(Window 3) Show OP data Write result
Operation :
NG - USB is no t find
NG – File(Budata.txt) is no t find
OK – OP data write
>Drive Test:
Fo r drive o perating check. Service is o nly us e Drive OP data write to re write
OP data after change o f new OPU.
(Window 4) Show OP Check Menu
Operation :
[1] Dis c : Eject
[2] OP Serial : **************
[3] dIOP
[4] LD ON Time
aararammeteteerr CChehecckk MM
enenuu iigngnaall CChehecckk M
Menenuu CChheeckck MMeennuu
llitityy CChhececkk MMee
nunu ttioionn CChhececk
k MMeenunu kk MMeenunu
eectct AAggiingng
CCoonntrtrooll CChehecckk MMen
enuu tt MMoodede
WWN]N][[ENENTT][][RRETET]][([(NNUMUM))]]
[E[ENNT]T] StStartart
HelpHelp:: [[UUP]P][[DODO
HELPHELP:: [[LLEFEFT][T][RIGRIGHT]HT][UP[UP][D][
DOWNOWN][E][ENT]NT][RE[RETT
RRIGIGHHT]T][[UPUP]][D[DOOWNWN]][E[ENNT]T][[RERETT]]
(Window 1)
* Drive
[1] Drive OP data Write
[2] Servo Parameter Check Menu
[3] Servo Signal Check Menu
[4] S-Curve Check Menu
[5] Readability Check Menu
[6] OP Position Check Menu
[7] OP Check Menu
[8] Aging Test Menu
[9] Spindle Control Check Menu
[10] FA Test Mode
HELP : [UP] [DOWN] [ENT] [RET] [(NUM)]
(Window 2)
* Drive OP data Write
HELP : [ENT] [RET]
[Insert USB StorageDevice …
Remove DISC and Close tray.
Disc: Eject
Mode: 1
[ENT] Start
(Window 3)
* Drive OP data Write
HELP : [ENT] [RET]
[Insert USB StorageDevice …
Remove DISC and Close tray.
[ENT] Start
NG - USB is not find
OK - OP data write
(Window 4)
* OP Check Menu
HELP : [ENT] [RET]
Remove DISC and Close tray.
[1] Disc: Eject
[2] OP Serial : xxxxxxxxxxxxxxxxx
[3] dIOP
BD : x [xx]
DVD : x [xx]
CD : x [xx]
TEMP : xx.x deg
[4] LD ON Time
Drive
