Inputs and outputs
AC adaptor (AC-M1215WW)
Wireless
General
Laser
Semiconductor laser
Jack name Jack type/Output level/Load impedance
DIGITAL OUT (COAXIAL) Phono jack /0.5 Vp-p/75 ohms
HDMI OUT 1*/2
HDMI 19-pin standard connector
* Only HDMI OUT 1 supports video output.
LAN (100) 100BASE-TX Terminal
USB
USB jack Type A (For connecting a USB memory, memory
card reader, digital still camera, and digital video
camera)*
* Do not use for power charging purposes.
DC IN 12 V DC 1.25 A
Input
100 V - 240 V 50/60 Hz, 500 mA
Output
12 V, 1 500 mA
Operating temperature
0 ºC to 45 ºC
Wireless LAN standard Protocol IEEE802.11b/g/n
Frequency range 2.4 GHz band
Modulation DSSS and OFDM
Power requirements 12 V DC 1.25 A with AC adaptor
Power consumption
(when using AC adaptor)
15 W
Dimensions (approx.)
320 mm × 217 mm × 45 mm
(width × depth × height) incl. projecting parts
Mass (approx.) 1.4 kg
Operating temperature 5 ºC to 35 ºC
Operating humidity 25 % to 80 %
v
Specifications : UBP-X700 E32
Specifications and design are subject to change without notice.
