8-8
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FR-127 MA-315
< COIL >
L420 1-414-934-21 INDUCTOR 10uH
< FLUORECENT INDICATOR >
ND420 1-517-724-21 TUBE, FLUORESCENT INDICATOR
< TRANSISTOR >
Q400 8-729-421-19 TRANSISTOR UN2213
< RESISTOR >
R400 1-249-407-11 CARBON 150 5% 1/4W F
R401 1-216-089-91 RES, CHIP 47K 5% 1/10W
R402 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R404 1-216-073-00 METAL CHIP 10K 5% 1/10W
R405 1-216-073-00 METAL CHIP 10K 5% 1/10W
R406 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R407 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R408 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R412 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R413 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R414 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R415 1-216-077-00 METAL CHIP 15K 5% 1/10W
R416 1-216-041-00 METAL CHIP 470 5% 1/10W
(E580EE)
R421 1-216-295-91 SHORT 0
R422 1-216-049-91 RES, CHIP 1K 5% 1/10W
R423 1-216-049-91 RES, CHIP 1K 5% 1/10W
R424 1-216-049-91 RES, CHIP 1K 5% 1/10W
R425 1-216-085-00 METAL CHIP 33K 5% 1/10W
R426 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R480 1-216-022-00 METAL CHIP 75 5% 1/10W
(E580/E780)
R490 1-216-041-00 METAL CHIP 470 5% 1/10W
(E780)
R491 1-216-041-00 METAL CHIP 470 5% 1/10W
(E580/E780)
< SWITCH >
S400 1-762-196-21 SWITCH, TACT (ON/STANDBY)
S401 1-762-196-21 SWITCH, TACT (CHANNEL +)
S402 1-762-196-21 SWITCH, TACT (RF CHANNEL)
S404 1-762-196-21 SWITCH, TACT (CHANNEL –)
S406 1-762-196-21 SWITCH, TACT (VIRTUAL STEREO) (E580EE)
S407 1-762-196-21 SWITCH, TACT (EJECT)
* A-6791-497-A MA-315 BOARD, COMPLETE (E730UX)
* A-6791-498-A MA-315 BOARD, COMPLETE (E730VP)
* A-6791-499-A MA-315 BOARD, COMPLETE
(E727/E730VC/E735VC)
* A-6791-503-A MA-315 BOARD, COMPLETE (E730B/E735B)
* A-6791-505-A MA-315 BOARD, COMPLETE (E730NP)
* A-6791-506-A MA-315 BOARD, COMPLETE
(E730NC/E735NC)
* A-6791-507-A MA-315 BOARD, COMPLETE (E630NP)
* A-6791-549-A MA-315 BOARD, COMPLETE (E730EX)
* A-6791-550-A MA-315 BOARD, COMPLETE (E630AE)
* A-6791-551-A MA-315 BOARD, COMPLETE (E780EG)
* A-6791-552-A MA-315 BOARD, COMPLETE (E780EN)
* A-6791-553-A MA-315 BOARD, COMPLETE (E780EE)
* A-6791-555-A MA-315 BOARD, COMPLETE (E580EG)
* A-6791-557-A MA-315 BOARD, COMPLETE (E580EE)
***********************
(Ref.No. 2,000 Series)
1-556-934-81 CABLE, PIN (EXCEPT E580/E780EE)
* 3-960-273-01 SPACER, TOP END
* 3-960-274-01 SPACER, LED
< CAPACITOR >
C100 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C101 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C103 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C104 1-128-057-11 ELECT 330uF 20% 6.3V
C107 1-124-589-11 ELECT 47uF 20% 16V
C110 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C111 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C112 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C113 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C114 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C115 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C117 1-124-589-11 ELECT 47uF 20% 16V
C131 1-124-589-11 ELECT 47uF 20% 16V
C133 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C134 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C161 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
(EXCEPT E580)
C162 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C163 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C164 1-124-584-00 ELECT 100uF 20% 10V
C165 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C166 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C167 1-124-584-00 ELECT 100uF 20% 10V
C168 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C169 1-104-905-11 CAPACITOR 0.22F 5.5V
C170 1-128-131-11 ELECT 22uF 20% 50V
C171 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C172 1-128-131-11 ELECT 22uF 20% 50V
C173 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C174 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C175 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C176 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C177 1-128-131-11 ELECT 22uF 20% 50V
C178 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C179 1-124-584-00 ELECT 100uF 20% 10V
C180 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C181 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C182 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C184 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C185 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C201 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C202 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C204 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C205 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C206 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C207 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C208 1-163-241-11 CERAMIC CHIP 39PF 5% 50V
C209 1-128-131-11 ELECT 22uF 20% 50V
C210 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
