8-7
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
8-2. ELECTRICAL PARTS LIST
DM-72 FR-127
* A-6794-516-A DM-72 BOARD, COMPLETE (EXCEPT E580)
* A-6794-521-A DM-72 BOARD, COMPLETE (E580)
**********************
(Ref.No. 1,000 Series)
< CONNECTOR >
CN451 1-784-484-11 CONNECTOR, FFC/FPC 5P (E580)
CN452 1-784-453-11 CONNECTOR, FFC/FPC 11P
< DIODE >
D459 8-719-056-06 DIODE SLR-342DCT31 (JOG) (E580)
< RESISTOR >
R452 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R453 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R454 1-216-295-91 SHORT 0
R455 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R456 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R457 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R458 1-216-041-00 METAL CHIP 470 5% 1/10W
(E580)
< SWITCH >
S451 1-762-196-21 SWITCH, TACT (REC)
S452 1-762-196-21 SWITCH, TACT (REW) (EXCEPT E580)
S453 1-762-196-21 SWITCH, TACT (REW) (E580)
S454 1-762-196-21 SWITCH, TACT (STOP) (EXCEPT E580)
S455 1-762-196-21 SWITCH, TACT (PLAY) (EXCEPT E580)
S456 1-762-196-21 SWITCH, TACT (FF) (EXCEPT E580)
S457 1-762-196-21 SWITCH, TACT (FF) (E580)
S458 1-762-196-21 SWITCH, TACT (PAUSE)
S459 1-762-196-21 SWITCH, TACT (JOG) (E580)
* A-6791-502-A FR-127 BOARD, COMPLETE
(E630/E727/E730/E735)
* A-6791-554-A FR-127 BOARD, COMPLETE (E780)
* A-6791-556-A FR-127 BOARD, COMPLETE (E580EG)
* A-6791-559-A FR-127 BOARD, COMPLETE (E580EE)
***********************
(Ref.No. 1,000 Series)
* 3-972-888-01 HOLDER (85), FL
< CAPACITOR >
C400 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C421 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C422 1-124-589-11 ELECT 47uF 20% 16V
C423 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C424 1-124-589-11 ELECT 47uF 20% 16V
C481 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(E580/E780)
C491 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(E780)
C493 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(E580/E780)
< CONNECTOR >
CN400 1-784-453-11 CONNECTOR, FFC/FPC 11P
CN420 1-784-458-11 CONNECTOR, FFC/FPC 16P
* CN480 1-568-954-11 PIN, CONNECTOR 5P (E780)
CN480 1-506-469-11 PIN, CONNECTOR 4P (E580)
< DIODE >
D400 8-719-056-07 DIODE SLR-342MCT31 (ON/STANDBY)
D401 8-719-045-63 DIODE SLR-342YCT31 (VIRTUAL STEREO)
(E580EE)
D480 8-719-109-97 DIODE RD6.8ES-B2 (E580/E780)
D481 8-719-109-97 DIODE RD6.8ES-B2 (E580/E780)
D482 8-719-109-97 DIODE RD6.8ES-B2 (E580/E780)
D490 8-719-109-97 DIODE RD6.8ES-B2 (E780)
D491 8-719-109-97 DIODE RD6.8ES-B2 (E580/E780)
D492 8-719-109-97 DIODE RD6.8ES-B2 (E580/E780)
D493 8-719-109-97 DIODE RD6.8ES-B2 (E780)
< IC >
IC400 8-749-011-05 IC GP1U28X
IC420 8-759-366-44 IC uPD16312GB-3B4
< JACK >
J480 1-766-861-21 JACK, PIN (3P) (LINE 2 IN) (E780)
J480 1-766-862-21 JACK, PIN (2P) (LINE 2 IN) (E580)
< JUMPER RESISTOR >
JS402 1-216-296-91 SHORT 0 (E630/E727/E730/E735)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
To Next Page
