Sony SLV-SE85 - Mechanism Deck Section-3

7-6
801 3-977-437-01 RETAINER,CAM MOTOR
802 X-3949-364-1 ASSY, REEL DIRECT SELECT (B)
803 3-977-443-01 WASHER, STOPPER
804 3-977-438-01 WORM - WHEEL
805 3-053-888-01 BASE, DIRECT SELECT (B)
806 3-977-444-01 GEAR, PINCH TRANSMISSION
807 3-977-515-01 GUIDE, FL SLIDER
808 3-977-517-01 PLATE, SLIDE, FL
809 3-977-519-01 SPRING, TENS. (LIMIT, FL)
810 3-977-518-02 PLATE, LIMITTER, FL
811 3-977-516-01 HOLDER, FL SLIDER
812 3-977-877-01 PLATE, RETAINER
813 3-977-504-01 GEAR, CLUTCH
814 X-3949-365-1 GEAR ASSY PULLEY (B)
815 3-977-510-01 BELT, RUBBER
816 3-977-440-01 WASHER, STOPPER
817 3-977-439-01 GEAR, CAM
818 3-053-878-01 SLIDER (B)
819 3-977-455-01 GEAR, LOADING(T)
820 3-977-456-03 SPRING, TORSION (LOAD T)
821 X-3947-579-1 LEVER ASSY, LOADING(T)
822 3-977-451-01 GEAR, LOADING(S)
823 3-977-452-01 SPRING, TORSION (LOAD S)
824 X-3947-578-1 LEVER ASSY, LOADING(S)
825 X-3947-576-2 CHASSIS ASSY, MECHANICAL
826 3-977-468-01 SHAFT, CAPSTAN BRAKE
827 3-977-467-02 SPRING, CAP BRAKE
828 X-3947-583-1 BRAKE ASSY, CAPSTAN
829 3-977-489-01 ARM, TG1 DRIVING
830 A-6759-616-A GEAR BLOCK ASSY, LOADING(S)
831 1-766-723-21 CONNECTOR, BOARD TO BOARD 3P
832 3-977-436-01 WORM
833 3-989-917-01 SPACER (REC PROOF)
834 1-666-524-11 PWB, CA-55
835 3-053-887-01 ARM, DIRECT SELECT (B)
836 3-053-889-01 SPRING, TORSION(DIRECT SELECT)
837 3-974-477-01 WASHER, (GEAR, LIMITTER)
838 1-541-309-11 MOTOR, L (RF-370C)
M902 1-698-971-11 MOTOR, DC (CAPSTAN)
M903 X-3947-577-1 MOTOR ASSY, CAM
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
816
817
803
818
819
820
821
822
823
824
825
#703
833
802
837
803
801
M903
832
838
831
834
804
805
836
835
809
810
808
807
806
812
811
#701
M902
815
814
813
803
828
827
829
826
830
7-1-5. MECHANISM DECK SECTION-3
