7-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
* A-6791-916-A AT-25 COMPLETE BOARD, COMPLETE
(SF90/SF99)
*************************************
(Ref.No.:2000 Series)
3-987-343-11 HOLDER, AN
< CAPACITOR >
C991 1-163-136-00 CERAMIC CHIP 620PF 1% 50V
< CONNECTOR >
CN990 1-506-468-11 PIN, CONNECTOR 3P
< RESISTOR >
R990 1-216-295-91 SHORT 0
R991 1-216-295-91 SHORT 0
************************************************************
* A-6791-912-A AT-26 COMPLETE BOARD, COMPLETE
(SF90/SF99)
*************************************
(Ref.No.:2000 Series)
3-054-863-11 HOLDER (DD), SHIELD (SF90/SF99)
< CAPACITOR >
C995 1-125-830-91 CERAMIC CHIP 680PF 1% 50V
(SF90/SF99)
C996 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
(SF90/SF99)
< CONNECTOR >
CN995 1-506-468-11 PIN, CONNECTOR 3P (SF90/SF99)
************************************************************
* A-6791-911-A DM-86 COMPLETE BOARD, COMPLETE
*******************************
(Ref.No.:3000 Series)
1-790-719-11 CABLE, FLAT (FFD-5)
< CAPACITOR >
C451 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN451 1-784-484-11 CONNECTOR, FFC/FPC 5P
CN452 1-784-449-11 CONNECTOR, FFC/FPC 7P
< DIODE >
D459 8-719-056-06 DIODE SLR-342DCT31(JOG)
< RESISTOR >
R459 1-216-033-00 METAL CHIP 220 5% 1/10W
R464 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R465 1-216-073-00 METAL CHIP 10K 5% 1/10W
R466 1-216-073-00 METAL CHIP 10K 5% 1/10W
R467 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R468 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R469 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R471 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R472 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
< SWITCH >
S451 1-771-410-21 SWITCH, TACT(r REC)
S453 1-771-410-21 SWITCH, TACT(0 REW)
S457 1-771-410-21 SWITCH, TACT() FF)
S458 1-771-410-21 SWITCH, TACT(P PAUSE)
S459 1-771-410-21 SWITCH, TACT(JOG)
************************************************************
AT-25 AT-26 DM-86
