7-8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
* A-6791-909-A FR-161 COMPLETE BOARD, COMPLETE
(SF90:VC(WF),VC(SF))
**************************************
* A-6791-921-A FR-161 COMPLETE BOARD, COMPLETE
(SF90:B(WF),B(SF))
**************************************
* A-6791-927-A FR-161 COMPLETE BOARD, COMPLETE
(SE85:B)
**************************************
* A-6791-930-A FR-161 COMPLETE BOARD, COMPLETE
(SE85:VC)
**************************************
* A-6791-931-A FR-161 COMPLETE BOARD, COMPLETE
(SE85:NP)
**************************************
* A-6791-932-A FR-161 COMPLETE BOARD, COMPLETE
(SE85:UX)
**************************************
* A-6791-933-A FR-161 COMPLETE BOARD, COMPLETE
(SF90:NP(WF),NP(SF))
**************************************
* A-6791-934-A FR-161 COMPLETE BOARD, COMPLETE
(SF90:UX(WF),UX(SF))
**************************************
* A-6791-935-A FR-161 COMPLETE BOARD, COMPLETE
(SF90:EX)
**************************************
* A-6791-956-A FR-161 COMPLETE BOARD, COMPLETE
(SF99:VC)
**************************************
* A-6791-957-A FR-161 COMPLETE BOARD, COMPLETE
(SF99:EN)
**************************************
* A-6791-958-A FR-161 COMPLETE BOARD, COMPLETE
(SF99:B)
**************************************
* A-6791-965-A FR-161 COMPLETE BOARD, COMPLETE
(SF99:NP)
**************************************
* A-6791-966-A FR-161 COMPLETE BOARD, COMPLETE
(SF99:UX)
**************************************
(Ref.No.:3000 Series)
1-790-718-11 CABLE, FLAT (FFM-31)
< BUZZER >
BZ181 1-529-104-11 BUZZER, PIEZOELECTRIC (EXCEPT SF99:UX)
< CAPACITOR >
C180 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(EXCEPT SF99:UX)
C188 1-163-104-00 CERAMIC CHIP 30PF 5% 50V
(EXCEPT SF99:UX)
C190 1-115-456-21 DOUBLE LAYER 0.22F 0 5.5V
(EXCEPT SF99:UX)
C191 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(EXCEPT SF99:UX)
C192 1-126-916-11 ELECT 1000uF 20% 6.3V
(EXCEPT SF99:UX)
C193 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(EXCEPT SF99:UX)
C196 1-128-057-11 ELECT 330uF 20% 6.3V
(EXCEPT SF99:UX)
C198 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(EXCEPT SF99:UX)
C199 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(EXCEPT SF99:UX)
C200 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(EXCEPT SF99:UX)
C400 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
(EXCEPT SF99:UX)
C401 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
(EXCEPT SF99:UX)
C402 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
(EXCEPT SF99:UX)
C403 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
(EXCEPT SF99:UX)
C421 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(EXCEPT SF99:UX)
C422 1-104-664-11 ELECT 47uF 20% 16V
(EXCEPT SF99:UX)
C423 1-163-031-11 CERAMIC CHIP 0.01uF 50V
(EXCEPT SF99:UX)
C424 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(EXCEPT SF99:UX)
C495 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(EXCEPT SF99:UX)
C496 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(EXCEPT SF99:UX)
C497 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
(EXCEPT SF99:UX)
< CONNECTOR >
CN400 1-784-449-11 CONNECTOR, FFC/FPC 7P (EXCEPT SF99:UX)
CN401 1-695-328-11 PIN, CONNECTOR (PC BOARD) 5P (SF90/SF99)
CN402 1-784-512-11 CONNECTOR, FFC/FPC 33P
< TRIMMER >
CT180 1-141-442-91 CAP, CERAMIC TRIMMER 20PF (EXCEPT
SF99:UX)
< DIODE >
D188 8-719-075-84 DIODE S1G-G2P (EXCEPT SF99:UX)
D189 8-719-075-84 DIODE S1G-G2P (EXCEPT SF99:UX)
D400 8-719-056-07 DIODE SLR-342MCT31 (EXCEPT SF99:UX)
D420 8-719-070-61 DIODE PDZ8.2B-115 (EXCEPT SF99:UX)
D421 8-719-056-06 DIODE SLR-342DCT31 (SF99:UX,EN,NP,VC)
FR-161
