Sony SLV-SE85 - Page 99

7-10
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R430 1-216-073-00 METAL CHIP 10K 5% 1/10W
R492 1-216-037-00 METAL CHIP 330 5% 1/10W
< SWITCH >
S400 1-771-410-21 SWITCH, TACT
S401 1-771-410-21 SWITCH, TACT
S402 1-771-410-21 SWITCH, TACT
S403 1-771-410-21 SWITCH, TACT
S404 1-771-410-21 SWITCH, TACT
S405 1-771-410-21 SWITCH, TACT
< VIBRATOR >
X180 1-760-014-11 VIBRATOR, CERAMIC
X181 1-579-463-11 VIBRATOR, CRYSTAL
************************************************************
* A-6791-910-A JK-171 COMPLETE BOARD, COMPLETE
********************************
(Ref.No.:3000 Series)
< CAPACITOR >
C481 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C491 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C493 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN480 1-568-954-11 PIN, CONNECTOR 5P
< DIODE >
D480 8-719-070-59 DIODE PDZ6.8B-115
D490 8-719-071-50 DIODE BZA408B-115
< JACK >
J480 1-774-509-11 JACK, PIN 3P
< JUMPER RESISTOR >
JR480 1-216-296-91 SHORT 0
JR481 1-216-295-91 SHORT 0
JS490 1-216-295-91 SHORT 0
< RESISTOR >
R480 1-216-022-00 METAL CHIP 75 5% 1/10W
R481 1-216-295-91 SHORT 0
R490 1-216-295-91 SHORT 0
R491 1-216-295-91 SHORT 0
************************************************************
* A-6791-913-A MA-359 COMPLETE BOARD, COMPLETE
(SF90:VC(WF),VC(SF))
**************************************
* A-6791-917-A MA-359 COMPLETE BOARD, COMPLETE
(SF90:UX(WF),UX(SF))
**************************************
* A-6791-919-A MA-359 COMPLETE BOARD, COMPLETE
(SF90:EX)
**************************************
* A-6791-920-A MA-359 COMPLETE BOARD, COMPLETE
(SF90:NP(WF),NP(SF))
**************************************
* A-6791-922-A MA-359 COMPLETE BOARD, COMPLETE
(SF90:B(WF),B(SF))
**************************************
* A-6791-924-A MA-359 COMPLETE BOARD, COMPLETE
(SE85:VC)
**************************************
* A-6791-926-A MA-359 COMPLETE BOARD, COMPLETE
(SE85:UX)
**************************************
* A-6791-928-A MA-359 COMPLETE BOARD, COMPLETE
(SE85:B)
**************************************
* A-6791-929-A MA-359 COMPLETE BOARD, COMPLETE
(SE85:NP)
**************************************
* A-6791-960-A MA-359 COMPLETE BOARD, COMPLETE
(SF99:EN)
**************************************
* A-6791-961-A MA-359 COMPLETE BOARD, COMPLETE
(SF99:VC)
**************************************
* A-6791-962-A MA-359 COMPLETE BOARD, COMPLETE
(SF99:NP)
**************************************
* A-6791-963-A MA-359 COMPLETE BOARD, COMPLETE
(SF99:B)
**************************************
* A-6791-964-A MA-359 COMPLETE BOARD, COMPLETE
(SF99:UX)
**************************************
(Ref.No.:1000 Series)
* 3-960-273-01 SPACER, TOP END
* 3-960-274-01 SPACER, LED
< CAPACITOR >
C001 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C002 1-126-933-11 ELECT 100uF 20% 16V
C003 1-164-346-11 CERAMIC CHIP 1uF 16V
C004 1-126-963-11 ELECT 4.7uF 20% 50V
C006 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
FR-161 JK-171 MA-359
