34
SYSTEM Menu
You can set the menu from the Administrator
menu on a web browser.
For details, see “[Installation] tab” (page 47).
IMG FLIP (System - Image flip)
When [IMG FLIP] is set to [ON], the picture is
flipped vertically and picture shift direction by
the pan/tilt operation is also reversed.
IR RECEIVE (System - IR receive)
(SRG-XP1 only)
If this is turned [OFF], the camera does not
receive signals from the supplied remote
commander.
Be sure to turn this [ON] when you use the
supplied remote commander.
Note
You cannot set [IR RECEIVE] to [OFF] when using
the supplied remote commander. Set [IR
RECEIVE] to [OFF] using the remote controller
(not supplied) or from the Administrator menu
on the web browser.
TALLY LEVEL (System - Tally level)
This allows you to configure the settings related
to the tally lamp on the front of the camera.
Select from [HIGH], [LOW], and [OFF].
[HIGH]: When the tally lamp is turned on, it
comes on bright.
[LOW]: When the tally lamp is turned on, it
comes on dim.
[OFF]: Even when the tally-lamp-ON command is
received, the tally lamp does not light up.
Note
When [TALLY LEVEL] is set to [OFF], the tally lamp
does not light up.
VISCA BAUD RATE (System - VISCA rate)
(SRG-XB25 only)
Sets the baud rate for VISCA RS-232
communication.
[9600]: 9600 bps
[38400]: 38400 bps
LDC (System - LDC) (SRG-XP1 only)
Sets the image distortion correction for the lens.
REBOOT
Used when forcibly rebooting the system. It takes
about 2 minutes to reboot.
6<67(0!
!,0*)/,32))
ࠉ7$//</(9(/ /2:
9,6&$%$8'5$7(
5(%227
