Sony SRW-5000 - Items Relating to the Video Control (Nos. 706 to

170
Menu List
Appendix
Items Relating to the Video Control (Nos. 706 to ...)
Item number Item Setting Function
706 FORCED
VERTICAL
INTERPOLATION
OFF
[auto]
forced YADD off
Specifies whether or not Y-add operation mode is
automatically turned on during DT playback.
auto: Y-add operation mode is automatically turned on.
forced YADD off: Y-add operation mode is off all the time.
707 ROUNDING
(SRW-5500 only)
[simple]
adaptive
Selects whether to perform A-ROUNDING
TM 1)
processing.
simple: Do not perform A-ROUNDING
TM
processing. 10-bit
input signals are simply rounded to 8 bits.
adaptive: Perform A-ROUNDING
TM
processing. 10-bit
input signals are adaptively rounded to 8 bits.
708 MASTER LEVEL
(HD)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Simultaneously adjusts the Y,
P
B
, and P
R
levels.
709 Y LEVEL (HD)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the Y level of the video
signal.
710 P
B
LEVEL (HD)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the P
B
level of the video
signal.
711 P
R
LEVEL (HD)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the P
R
level of the video
signal.
712 SETUP LEVEL (HD)
preset: 0
–10.0
[0.0]
10.0
Adjusts the level of the HD video signal output from the HD
SDI OUTPUT connectors. Adjusts the setup level of the
video signal.
713 SYNC PHASE (HD)
preset: 0
–128
[0]
127
Controls the H sync phase of the HD video signal output
from the HD SDI OUTPUT connectors, according to the
menu.
714 FINE (HD)
preset: 0
[0]
1024
Controls the H sync phase of the HD video signal output
from the HD SDI OUTPUT connectors, according to the
menu.
720 HD OUT BLANK [through]
blank
Turns on and off vertical interval blanking processing of the
HD video signals output from the HD SDI OUTPUT
connectors and the FORMAT CONV. OUT (OPTION)
connectors.
through: Do not perform blanking processing.
on: Perform blanking processing.
740 VIDEO GAIN (ALL)
(HD/UC/SD/DC)
preset: 100%
(4000H)
0.0% (0H)
141.3% (5A70H)
Adjusts the video gain of HD, UC, SD, and DC output. The
video level increases with larger setting values of this item.
