Menu List
Appendix
814 LEVEL METER
SCALE
[peak 0 dB]
reference 0 dB
Specifies the mode in which the digital audio level is
displayed.
peak 0 dB: Displays minus audio levels with the maximum
level set at 0 dB.
reference 0 dB: Displays plus and minus audio levels with
the reference level set at 0 dB.
Note
The CUE channel level is always displayed with the
reference level set at 0 dB.
815 AUDIO OUTPUT
PHASE
preset: 128
0
[128]
255
Sets the output timing for the digital audio playback signal
(SDI and AES/EBU only). The 128 setting specifies the
reference position.
A setting lower than 128 advances the output timing, and a
setting higher than 128 delays the output timing.
(128 samples, or approx. 2.7 ms, with 1 sample = approx.
20 µs)
816 PITCH
CORRECTION
[off]
on
Selects whether or not to perform pitch correction during
program play and play at a different frequency (23.98 frame
y 24 frame, 23.98/24 frame y 25 frame, 29.97 frame
y 30 frame).
off: Output audio with no pitch correction.
on: Output audio with pitch correction.
Item number Item Setting Function
