Sony STR-DA333ES - Page 35

– 61 –
IC103 LB1638MTE (DISPLAY BOARD)
1
2
3
4
5 6
7
8
9
10
GND
IN1
VCC
IN2
GND
N.C.
OUT2
VS
OUT1
N.C.
CONTROL LOGIC
IC202,203 LC7821 (MAIN/AUDIO BOARD)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
CONTROL
LATCH
SHIFT RESISTER
LEVEL SHIFT
CL
DI
CE
VEE
L COM3
L7
L COM2
L5
L4
L2
VSS
S
RES
VDD
R COM3
R8
R7
R COM2
R6
R4
R2
R5
R COM1
R3
R1
L3
L1
L COM1
L6
L8
BUFFER
IC901 NJM2103D (PS BOARD)
1
2
3
4
5
6
7
8
V+
VSB/SESIN
VSA
RESET
GND
OUTC
VSC
CR
VREF
+
–
–
+
–
+
–
+
Q
R S
IC501,601,701 uPC2581V (REAR AMP/MAIN BOARD)
2
3
5
4
6
7
98
1
MUTE
+ VOUT1 – VOUT1
COMP1
MF1
IN1
GND
IN2
NF2
COMP2
– VOUT2 + VOUT2
VCC1 VCC2
VEE
PROTECTOR
BIAS CIRCUIT
REG DRIVE
PRE
DRIVE
11
10
12
13
1514
DRIVE
PRE
DRIVE
