– 74 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
5.1 INPUT
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
Note:
When indicating parts by reference
number, please include the board
name.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
* 1-670-134-11 5.1 INPUT BOARD
***************
< CAPACITOR >
C354 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C355 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C356 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C357 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C358 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C359 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C360 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C361 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CNP351 1-779-799-11 PIN, CONNECTOR 9P
CNP352 1-784-922-11 PIN, CONNECTOR 5P
< JACK >
J351 1-779-685-11 JACK, PIN 6P (5.1 INPUT)
J352 1-785-009-11 JACK, PIN 6P (FRONT/REAR WOOFER)
J353 1-774-785-11 JACK, PIN 1P (CENTER)
< RESISTOR >
R361 1-216-049-91 RES,CHIP 1K 5% 1/10W
R362 1-216-049-91 RES,CHIP 1K 5% 1/10W
R363 1-216-049-91 RES,CHIP 1K 5% 1/10W
R364 1-216-049-91 RES,CHIP 1K 5% 1/10W
R365 1-216-049-91 RES,CHIP 1K 5% 1/10W
R366 1-216-049-91 RES,CHIP 1K 5% 1/10W
R367 1-216-049-91 RES,CHIP 1K 5% 1/10W
R368 1-216-049-91 RES,CHIP 1K 5% 1/10W
R369 1-216-049-91 RES,CHIP 1K 5% 1/10W
R370 1-216-049-91 RES,CHIP 1K 5% 1/10W
R371 1-216-049-91 RES,CHIP 1K 5% 1/10W
R372 1-216-049-91 RES,CHIP 1K 5% 1/10W
R373 1-216-075-00 METAL CHIP 12K 5% 1/10W
(DA333ES)
R373 1-216-077-00 METAL CHIP 15K 5% 1/10W
(DA555ES)
R374 1-216-075-00 METAL CHIP 12K 5% 1/10W
(DA333ES)
R374 1-216-077-00 METAL CHIP 15K 5% 1/10W
(DA555ES)
R375 1-216-075-00 METAL CHIP 12K 5% 1/10W
(DA333ES)
R375 1-216-077-00 METAL CHIP 15K 5% 1/10W
(DA555ES)
R376 1-216-075-00 METAL CHIP 12K 5% 1/10W
(DA333ES)
R376 1-216-077-00 METAL CHIP 15K 5% 1/10W
(DA555ES)
R377 1-216-075-00 METAL CHIP 12K 5% 1/10W
(DA333ES)
R377 1-216-077-00 METAL CHIP 15K 5% 1/10W
(DA555ES)
R378 1-216-075-00 METAL CHIP 12K 5% 1/10W
(DA333ES)
R378 1-216-077-00 METAL CHIP 15K 5% 1/10W
(DA555ES)
R380 1-216-049-91 RES,CHIP 1K 5% 1/10W
R381 1-216-049-91 RES,CHIP 1K 5% 1/10W
R382 1-216-049-91 RES,CHIP 1K 5% 1/10W
R383 1-216-049-91 RES,CHIP 1K 5% 1/10W
R384 1-216-049-91 RES,CHIP 1K 5% 1/10W
R385 1-216-049-91 RES,CHIP 1K 5% 1/10W
**************************************************************
* 1-670-132-11 AC BOARD
********
< CONNECTOR >
CNP902 1-564-321-00 PIN, CONNECTOR 2P
CNP903 1-564-321-00 PIN, CONNECTOR 2P
* CNP905 1-565-792-11 PIN, CONNECTOR 2P
* CNP907 1-568-951-11 PIN, CONNECTOR 2P
< DIODE >
D907 8-719-911-19 DIODE 1SS119-25
< FUSE >
! F901 1-533-312-11 FUSE, GLASS CYLINDRICAL (DIA.5)(10A/125V)
< FUSE HOLDER >
FH901 1-533-217-31 HOLDER, FUSE
FH901 1-533-293-11 FUSE HOLDER
FH901 1-533-399-31 HOLDER, FUSE
FH951 1-533-217-31 HOLDER, FUSE
FH951 1-533-293-11 FUSE HOLDER
FH951 1-533-399-31 HOLDER, FUSE
< JACK >
! J901 1-251-718-11 OUTLET (2 GANG), AC
AC
