– 75 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BAL. VOLAUDIO DIGITAL
< RESISTOR >
! R901 1-202-725-00 SOLID 3.3M 10% 1/2W
< RELAY >
! RY901 1-515-999-11 RELAY, POWER
**************************************************************
* A-4414-263-A AUDIO BOARD, COMPLETE
*********************
< CAPACITOR >
C291 1-162-294-31 CERAMIC 0.001uF 10% 50V
C292 1-126-048-81 ELECT 10uF 20% 50V
C293 1-126-048-81 ELECT 10uF 20% 50V
C294 1-126-048-81 ELECT 10uF 20% 50V
C295 1-162-282-31 CERAMIC 100PF 10% 50V
C296 1-126-048-81 ELECT 10uF 20% 50V
C301 1-164-159-11 CERAMIC 0.1uF 50V
C309 1-126-009-81 ELECT 100uF 20% 16V
C310 1-126-009-81 ELECT 100uF 20% 16V
C311 1-126-009-81 ELECT 100uF 20% 16V
C312 1-162-282-31 CERAMIC 100PF 10% 50V
C313 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CNP201 1-784-924-11 PIN, CONNECTOR 8P
CNP202 1-779-978-11 PIN, CONNECTOR 3P
CNP304 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
< IC >
IC203 8-759-805-13 IC LC7821
IC205 8-759-634-51 IC M5218AP
IC302 8-759-708-05 IC NJM78L05A
IC303 8-759-708-12 IC NJM78L12A
< JACK >
J210 1-784-920-11 JACK, PIN 6P (VIDEO1/IN/OUT, VIDEO2 IN)
J211 1-784-920-11 JACK, PIN 6P (VIDEO2 OUT, LD/DVD, TV/DBS)
< RESISTOR >
R222 1-249-417-11 CARBON 1K 5% 1/4W F
R223 1-249-417-11 CARBON 1K 5% 1/4W F
R224 1-249-417-11 CARBON 1K 5% 1/4W F
R225 1-249-417-11 CARBON 1K 5% 1/4W F
R226 1-249-417-11 CARBON 1K 5% 1/4W F
R227 1-249-417-11 CARBON 1K 5% 1/4W F
R269 1-247-807-31 CARBON 100 5% 1/4W
R271 1-247-807-31 CARBON 100 5% 1/4W
R272 1-249-417-11 CARBON 1K 5% 1/4W F
R273 1-249-417-11 CARBON 1K 5% 1/4W F
R274 1-249-417-11 CARBON 1K 5% 1/4W F
R275 1-249-417-11 CARBON 1K 5% 1/4W F
R276 1-249-417-11 CARBON 1K 5% 1/4W F
R277 1-249-417-11 CARBON 1K 5% 1/4W F
R291 1-249-441-11 CARBON 100K 5% 1/4W
R292 1-249-441-11 CARBON 100K 5% 1/4W
R295 1-249-417-11 CARBON 1K 5% 1/4W F
R296 1-249-425-11 CARBON 4.7K 5% 1/4W F
R304 1-249-417-11 CARBON 1K 5% 1/4W F
R305 1-249-417-11 CARBON 1K 5% 1/4W F
R306 1-247-807-31 CARBON 100 5% 1/4W
R307 1-249-417-11 CARBON 1K 5% 1/4W F
R308 1-249-417-11 CARBON 1K 5% 1/4W F
R309 1-249-417-11 CARBON 1K 5% 1/4W F
R379 1-249-417-11 CARBON 1K 5% 1/4W F
**************************************************************
* 1-670-140-11 BAL.VOL BOARD
*************
< CONNECTOR >
CNS404 1-770-398-11 HOUSING, CONNECTOR(PC BOARD)5P
< VARIABLE RESISTOR >
RV1140 1-225-663-11 RES, VAR, CARBON 100K/100K (BALANCE)
**************************************************************
* A-4414-292-A DIGITAL BOARD, COMPLETE
***********************
< CAPACITOR >
C1101 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C1102 1-126-008-51 ELECT 47uF 20% 16V
C1103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1104 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1105 1-126-008-51 ELECT 47uF 20% 16V
C1106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1107 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C1108 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1109 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1110 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C1111 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1113 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1114 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1115 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1116 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1117 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1118 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1119 1-126-009-81 ELECT 100uF 20% 16V
C1120 1-126-009-81 ELECT 100uF 20% 16V
C1123 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1124 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1125 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1126 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1127 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1128 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1129 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1130 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1131 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1132 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1133 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1134 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1135 1-126-009-81 ELECT 100uF 20% 16V
