Sony STR-DA333ES - Power Switch

– 86 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
PRE AMP
POWER SWITCH
! R685 1-249-393-11 CARBON 10 5% 1/4W F
R991 1-249-417-11 CARBON 1K 5% 1/4W F
(DA555ES)
R993 1-249-433-11 CARBON 22K 5% 1/4W
(DA555ES)
R995 1-249-441-11 CARBON 100K 5% 1/4W
(DA555ES)
R996 1-249-429-11 CARBON 10K 5% 1/4W
! R997 1-215-910-00 METAL OXIDE 68 5% 3W F
(DA555ES)
< VARIABLE RESISTOR >
RV501 1-241-759-11 RES, ADJ, CARBON 220
RV551 1-241-759-11 RES, ADJ, CARBON 220
RV601 1-241-759-11 RES, ADJ, CARBON 220
< RELAY >
RY401 1-515-793-11 RELAY
RY501 1-515-920-11 RELAY (24V)
RY502 1-515-920-11 RELAY (24V)
RY503 1-515-793-11 RELAY
RY504 1-515-793-11 RELAY
RY601 1-515-920-11 RELAY (24V)
RY602 1-515-793-11 RELAY
< TEST PIN >
* TP501 1-560-060-00 PIN, CONNECTOR 2P
* TP551 1-560-060-00 PIN, CONNECTOR 2P
* TP601 1-560-060-00 PIN, CONNECTOR 2P
**************************************************************
* 1-670-141-11 MAIN VOL BOARD
**************
< CAPACITOR >
C1492 1-126-008-51 ELECT 47uF 20% 16V
C1493 1-126-008-51 ELECT 47uF 20% 16V
C1501 1-126-044-11 ELECT 1uF 20% 50V
C1502 1-126-044-11 ELECT 1uF 20% 50V
< CONNECTOR >
CNP401 1-784-924-11 PIN, CONNECTOR 8P
CNP403 1-779-978-11 PIN, CONNECTOR 3P
CNP404 1-770-389-11 PIN, CONNECTOR (PC BOARD) 5P
CNP405 1-784-921-11 PIN, CONNECTOR 4P
* CNP407 1-564-522-11 PLUG, CONNECTOR 7P
CNP409 1-784-923-11 PIN, CONNECTOR 7P
CNP1406 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
< RESISTOR >
R1496 1-249-397-11 CARBON 22 5% 1/4W F
R1497 1-249-397-11 CARBON 22 5% 1/4W F
< VARIABLE RESISTOR >
RV1501 1-225-445-11 RES, VAR, CARBON 100KX6 (MASTER VOLUME)
**************************************************************
* 1-670-749-11 POWER SWITCH BOARD
******************
< SWITCH >
S101 1-572-184-11 SWITCH, KEYBOARD (1/u)
**************************************************************
* A-4414-252-A PRE AMP BOARD, COMPLETE
***********************
< CAPACITOR >
C1401 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1403 1-126-049-11 ELECT 22uF 20% 50V
C1404 1-126-049-11 ELECT 22uF 20% 50V
C1410 1-126-049-11 ELECT 22uF 20% 50V
C1411 1-126-049-11 ELECT 22uF 20% 50V
C1412 1-126-049-11 ELECT 22uF 20% 50V
C1415 1-126-049-11 ELECT 22uF 20% 50V
C1416 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1417 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1418 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1419 1-126-049-11 ELECT 22uF 20% 50V
C1420 1-126-049-11 ELECT 22uF 20% 50V
C1421 1-126-049-11 ELECT 22uF 20% 50V
C1460 1-126-049-11 ELECT 22uF 20% 50V
C1461 1-126-049-11 ELECT 22uF 20% 50V
C1462 1-126-049-11 ELECT 22uF 20% 50V
C1463 1-126-049-11 ELECT 22uF 20% 50V
C1464 1-126-049-11 ELECT 22uF 20% 50V
C1465 1-126-049-11 ELECT 22uF 20% 50V
C1466 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1467 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1468 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C1469 1-126-049-11 ELECT 22uF 20% 50V
C1470 1-126-049-11 ELECT 22uF 20% 50V
C1471 1-126-049-11 ELECT 22uF 20% 50V
< CONNECTOR >
* CNP1403 1-568-939-11 PIN, CONNECTOR 12P
CNS1402 1-779-799-11 PIN, CONNECTOR 9P
CNS1406 1-774-292-11 HOUSING,CONNECTOR(PC BOARD)15P
< DIODE >
D1401 8-719-820-05 DIODE 1SS181
D1402 8-719-820-05 DIODE 1SS181
D1403 8-719-820-05 DIODE 1SS181
D1404 8-719-820-05 DIODE 1SS181
D1405 8-719-820-05 DIODE 1SS181
D1406 8-719-820-05 DIODE 1SS181
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
MAIN MAIN VOL
