STR-DA5400ES
141
Pin No. Pin Name I/O Description
69, 70 D25, D24 I Serial data input from the HDMI receiver
71 to 75 D23 to D19 I Serial data input from the HDMI receiver and video processor1
76 CVCC18 - Power supply terminal (+1.8V)
77 to 81 D18 to D14 I Serial data input from the HDMI receiver and video processor1
82, 83 D13, D12 I Serial data input from the HDMI receiver
84 to 86 D11 to D9 I Serial data input from the HDMI receiver and video processor1
87 GND - Ground terminal
88 IDCK I Output data clock signal input from the clock generator
89 IOVCC33 - Power supply terminal (+3.3V)
90 to 98 D8 to D0 I Serial data input from the HDMI receiver and video processor1
99 CVCC18 - Power supply terminal (+1.8V)
100 GND - Ground terminal
