Sony STR-DA5400ES - 3-10. POWER TRANSFORMER (T1), E-VOL;MAIN BOARDS

STR-DA5400ES
20
3-10. POWER TRANSFORMER (T1), E-VOL/MAIN BOARDS
RL
four screws
(BVTP3
×
8)
RG
lead wire with connector
(CN1001)
RI
lead wire with connector
X
screw
(BVTP3
×
8)
RM
three screws
(BV/ring)
RH
Cut the clamp.
RH
Cut the
clamp.

two screws
(BVTP3
×
8)
XT
three screws
(BVTP3
×
8)
RK
two accessory
screws (J1499)
RE
two fuses (T4AL/250V)
(F1403, F1404)
J1499

screw
(BVTP3
×
8)
R
screw
(BVTP3
×
8)
RB
reinforcement
(DM/MAIN)
XB
reinforcement (MAIN)
RT
E-VOL board
XE
MAIN board

bracket
(SS)

copper washer
+BVTT assies

label (TR-ES/L)

power
transformer
(T1)

two connectors
(CN1404, CN1408)

two connectors
(CN1208, CN1209)

two connectors
(CN1203, CN1204)
